Green ATX motherboard with black slots, silver heatsinks and rear I/O shield

MSI

MSI Z390-S01 Intel motherboard LGA 1151 Z390 ATX DDR4 M.2

SKU CH-MGZV-B4NZT

ATX Intel Z390 board with LGA 1151 socket, four DDR4 slots up to 128 GB, two M.2 and four SATA ports, 7.1-channel audio and gigabit LAN

  • CPU TypeCore i7 / i5 / i3 (LGA1151)
  • Supports 9th and 8th gen Intel Core CPUs via LGA 1151 socket
  • Four DDR4 DIMM slots handle up to 128 GB dual-channel memory at 2133 MHz
  • Two M.2 slots plus four SATA III ports give flexible storage expansion
  • Realtek ALC892 7.1-channel audio with Realtek RTL8111H Gigabit LAN built in
  • Rear I/O includes USB 3.1 Gen2 Type-C and Type-A plus DVI, DisplayPort, HDMI video out

MSI Z390-S01 Motherboard for 8th

The MSI Z390-S01 is an ATX motherboard built on the Intel Z390 chipset with an LGA 1151 socket. It supports 8th and 9th generation Core i9, i7, i5, i3, Pentium and Celeron processors. The board provides four DDR4 DIMM slots for dual-channel memory up to 128 GB at 2133 MHz. It includes two M.2 slots and four SATA III ports for storage expansion.

Suits builders using 8th

This board fits builders who need an LGA 1151 platform with Z390 features such as CPU overclocking support and multi-GPU capability via two PCI-E 3.0 x16 slots. It also provides 7.1-channel audio through the Realtek ALC892 codec and gigabit LAN via the Realtek RTL8111H controller. Buyers who require a newer socket, a different chipset or integrated wireless connectivity should consider other options.

The LGA 1151 socket defines CPU compatibility

Only 8th and 9th generation Intel Core, Pentium and Celeron processors with the LGA 1151 package will fit this motherboard. The Z390 chipset enables overclocking for unlocked K-series CPUs such as the 9700K and 9900K. Memory must be DDR4 and storage uses the two M.2 interfaces or four SATA III connectors.

Highlights

  • Supports 9th and 8th gen Intel Core CPUs via LGA 1151 socket
  • Four DDR4 DIMM slots handle up to 128 GB dual-channel memory at 2133 MHz
  • Two M.2 slots plus four SATA III ports give flexible storage expansion
  • Realtek ALC892 7.1-channel audio with Realtek RTL8111H Gigabit LAN built in
  • Rear I/O includes USB 3.1 Gen2 Type-C and Type-A plus DVI, DisplayPort, HDMI video out

Specifications

CPU TypeCore i7 / i5 / i3 (LGA1151)

Questions about this item

What processor socket must my CPU match for this Z390-S01 board?

The board uses the LGA 1151 socket, so the installed processor must fit that socket.

Will my existing DDR4 2133 MHz memory modules work in the four DIMM slots?

Yes, the board supports dual-channel DDR4 at 2133 MHz across its four slots.

How can I confirm the onboard audio is active after assembly?

The Realtek ALC892 7.1-channel codec will appear in the operating system's sound devices once drivers are installed.
