Green Micro ATX motherboard with silver LGA 1151 socket and black DDR4 slots

MSI

MSI Z390-S01 Intel Z390 LGA 1151 DDR4 128GB Micro ATX Motherboard

SKU CH-4ZJW-5MS9M

Supports 9th Gen Intel Core, Pentium and Celeron LGA 1151 CPUs with DDR4 memory up to 4400 MHz and 128 GB capacity on a Micro ATX board

  • CPU Socket TypeLGA 1151
  • CPU Type9th Gen Intel Core ™, Pentium and Celeron processors with LG
  • ChipsetIntel Z390
  • Memory StandardSupports up to DDR4 4400MHz memory
  • Maximum Memory Supported128GB
  • PCI Slots2 PCIe 3.0 x16 slots 3 PCIe 3.0 x1 slots 1 M.2 slot with E k
  • Supports 9th Gen Intel Core, Pentium and Celeron CPUs with LGA 1151 socket
  • Handles up to 128 GB DDR4 memory at 4400 MHz
  • Two PCIe 3.0 x16 slots plus three PCIe 3.0 x1 slots for expansion
  • Realtek ALC892 delivers 7.1 channel high-quality audio
  • Two USB 3.1 Gen2 10 Gbps ports (Type-A and Type-C) plus eight USB 3.1 Gen1 ports

Z390 chipset for 9th Gen Intel Core

The MSI Z390-S01 motherboard pairs the Intel Z390 chipset with an LGA 1151 socket for 9th Gen Intel Core, Pentium and Celeron processors. It fits Micro ATX cases and targets builders who want a compact board with a full feature set.

DDR4 4400MHz support under sustained load

Four DDR4 slots accept up to 128GB of memory running at 4400MHz, keeping bandwidth available during long rendering or compile sessions. Two PCIe 3.0 x16 slots and three PCIe 3.0 x1 slots handle graphics and add-in cards without reducing lane allocation when all are populated.

Realtek ALC892 audio with 7.1 channels

The Realtek ALC892 codec delivers 7.1 channel output for surround setups. Rear I/O includes two USB 3.1 Gen2 ports — one Type-A and one Type-C — plus four USB 3.1 Gen1 Type-A ports, while four more Gen1 ports sit on internal headers. A single M.2 E-key slot accepts only an Intel CNVi wireless module, and six SATA III ports plus two M.2 interfaces provide storage connectivity.

Highlights

  • Supports 9th Gen Intel Core, Pentium and Celeron CPUs with LGA 1151 socket
  • Handles up to 128 GB DDR4 memory at 4400 MHz
  • Two PCIe 3.0 x16 slots plus three PCIe 3.0 x1 slots for expansion
  • Realtek ALC892 delivers 7.1 channel high-quality audio
  • Two USB 3.1 Gen2 10 Gbps ports (Type-A and Type-C) plus eight USB 3.1 Gen1 ports

Specifications

BrandMSI
SeriesMSI Z390-S01
ModelMSI Z390-S01
CPU Socket TypeLGA 1151
CPU Type9th Gen Intel Core ™, Pentium and Celeron processors with LGA1151 pin support
ChipsetIntel Z390
Memory StandardSupports up to DDR4 4400MHz memory
Maximum Memory Supported128GB
PCI Slots2 PCIe 3.0 x16 slots
3 PCIe 3.0 x1 slots
1 M.2 slot with E key for Integrated Intel Wireless-AC (CNVi) module only
SATA RAID2XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC892 decoding chip
7.1 channel high-quality sound effects
LAN Chipset1 Realtek Gigabit network interface card
Onboard USBIntel Z390 chipset
2 USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-A port and 1 Type-C port on the backplane)
8 USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the backplane, 4 via onboard USB 3.1 ports)
4 USB 2.0 (High-speed USB) interfaces (4 provided via onboard interface)

Questions about this item

How much power does the MSI Z390-S01 draw when running all day?

The board uses the Intel Z390 chipset and supports 9th Gen Intel Core, Pentium and Celeron processors; total system power will depend on the specific CPU and components installed.

What CPU cooler mounting does the MSI Z390-S01 require that I must already own?

The motherboard uses the LGA 1151 socket, so you need a cooler with LGA 1151 mounting hardware.

Will my existing DDR4 4400MHz memory work at its rated speed on the MSI Z390-S01?

The board supports up to DDR4 4400MHz and a maximum of 128GB across its memory slots.
