Green micro-ATX board with silver LGA 1151 socket, four black DDR4 slots, two M.2 sockets, black PCIe x16 slots, black rear I/O cover

MSI

MSI Z390M-S01 LGA 1151 Intel Z390 DDR4 Micro ATX Motherboard

SKU CH-KAZB-GME1T

Micro ATX board with Intel Z390 chipset, LGA 1151 socket for 8th/9th gen CPUs, four DDR4 slots up to 128 GB, dual M.2, USB 3.1 Gen2 Type-C and SATA RAID 0/1/5/10

  • CPU Socket TypeLGA 1151
  • CPU Type8th/9th generation Core i9/i7/i5/i3/Pentium/Celeron
  • Supported CPU TechnologiesSupport for Windows® 10 64-bit
  • ChipsetIntel Z390
  • Onboard Video ChipsetRealtek® ALC892 Codec
  • Number of Memory Slots4x288pin (DDR4)
  • Supports 8th and 9th generation Intel Core processors with LGA 1151 socket
  • Dual M.2 slots provide fast storage expansion options
  • Four DDR4 memory slots support up to 128 GB capacity
  • USB 3.1 Gen 2 Type C and Type A ports deliver high-speed connectivity
  • Micro ATX form factor fits compact builds while retaining Z390 chipset features

Z390 Micro ATX Platform

The MSI Z390M-S01 is a Micro ATX motherboard built around the Intel Z390 chipset and the LGA 1151 socket. It accepts 8th and 9th generation Core i9, i7, i5, i3, Pentium and Celeron processors. Four DDR4 slots support dual channel memory up to 128 GB.

Ideal for Compact Builds

This board suits builders who want Z390 features in a smaller chassis and do not need more than two full length expansion cards. It provides two PCI Express x16 slots and one x1 slot. Users requiring three or more add in cards or extensive rear I/O should consider a full size ATX alternative.

Memory and Storage Headroom

DDR4 speeds up to 4400 MHz overclocked and 2666 MHz native give wide headroom for memory tuning. Two M.2 sockets and SATA RAID 0, 1, 5, 10 handle multiple drives comfortably. The six USB 3.1 ports cover most peripherals, while the two USB 2.0 headers serve legacy devices.

Highlights

  • Supports 8th and 9th generation Intel Core processors with LGA 1151 socket
  • Dual M.2 slots provide fast storage expansion options
  • Four DDR4 memory slots support up to 128 GB capacity
  • USB 3.1 Gen 2 Type C and Type A ports deliver high-speed connectivity
  • Micro ATX form factor fits compact builds while retaining Z390 chipset features

Specifications

BrandMSI
SeriesMicro ATX
ModelZ390M-S01
CPU Socket TypeLGA 1151
CPU Type8th/9th generation Core i9/i7/i5/i3/Pentium/Celeron
Supported CPU TechnologiesSupport for Windows® 10 64-bit
ChipsetIntel Z390
Onboard Video ChipsetRealtek® ALC892 Codec
Number of Memory Slots4x288pin (DDR4)
Memory Standard4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) / 2800(OC)/ 2666/ 2400/ 2133 MHz
Maximum Memory Supported128GB
Channel SupportedDual Channel
PCI Express x162 x PCI Express x16
PCI Express x11 x PCI Express x1
PCI SlotsGen3
M.22 x M.2
SATA RAID0/1/5/10
Audio ChannelsRealtek® ALC892 Codec
USB 3.12(Gen1, Header) 1(Gen2, Type C), 1(Gen2, Type A)
USB 1.1/2.02 x USB 2.0
FeaturesMSI® does not guarantee the risks or damages caused by changing the cover.These pictures are for reference only and may vary without notice.
Package Contents4 DDR4 slots, supporting a total of up to 128GB Support DDR4 4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC) )/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) / 2800(OC)/ 2666/ 2400/ 2133 MHz Support dual channel mode Support non-ECC, unbuffered memory Support Intel® Extreme Memory Profile (XMP)

Questions about this item

What CPU socket and generation must I already have for this Z390M-S01 board to work?

The board uses the LGA 1151 socket and supports 8th and 9th generation Core i9, i7, i5, i3, Pentium and Celeron processors.

Can I keep my existing DDR4 memory kits when moving to this motherboard?

Yes, the four 288-pin slots accept DDR4 from 2133 up to 4400(OC) MHz in dual-channel mode, with a maximum capacity of 128 GB.

How can I verify the board is operating correctly after assembly?

Power on and confirm the system posts, then check the BIOS memory frequency matches your kit's rated speed and that all connected SATA and M.2 drives appear in the device list.
