Green micro ATX motherboard with silver heatsinks and black PCB

MSI

MSI Z490M-S01 Intel motherboard LGA1200 DDR4 128GB Micro ATX

SKU CH-ZAH0-K46G3

Micro-ATX Intel Z490 board with LGA 1200 socket, four DDR4 slots for up to 128 GB, dual CrossFire support and 7.1-channel audio

  • CPU Socket TypeLGA 1200
  • CPU TypeCore i9 / i7 / i5 / i3 (11th / 10th Gen, LGA1200)
  • ChipsetIntel Z490
  • Memory Standard4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/
  • Maximum Memory Supported128GB
  • Channel SupportedDual Channel
  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Intel Z490 chipset enables overclocking headroom for unlocked CPUs
  • Up to 128 GB DDR4 across four slots with XMP profiles
  • Micro ATX 244 mm form factor fits compact builds
  • 1-channel high-definition audio for immersive sound

Z490 Micro ATX motherboard for LGA 1200

The MSI Z490M-S01 is a Micro ATX board built on the Intel Z490 chipset for LGA 1200 processors. It accepts 10th and 11th Generation Core i9, i7, i5 and i3 CPUs. Four DDR4 slots support up to 128 GB of memory in dual-channel mode. The board measures 244 mm by 244 mm.

Suits builders who need overclocking headroom

Enthusiasts who want Z490 features such as CPU and memory overclocking plus 2-way AMD CrossFire support will find the feature set adequate. Users requiring a full-size ATX layout, integrated Wi-Fi, or more than two M.2 slots should consider other form factors.

Maximum memory capacity is 128 GB across four DDR4

This limit defines whether the board can handle the planned workload. The slots run at JEDEC speeds of 2133, 2400, 2666 and 2933 MHz and support XMP profiles up to 4000 MHz and beyond. Populate all four slots with 32 GB modules to reach the ceiling.

Highlights

  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Intel Z490 chipset enables overclocking headroom for unlocked CPUs
  • Up to 128 GB DDR4 across four slots with XMP profiles
  • Micro ATX 244 mm form factor fits compact builds
  • 1-channel high-definition audio for immersive sound

Specifications

ModelZ490M-S01
CPU Socket TypeLGA 1200
CPU TypeCore i9 / i7 / i5 / i3 (11th / 10th Gen, LGA1200)
ChipsetIntel Z490
Memory Standard4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) /2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) MHz
Maximum Memory Supported128GB
Channel SupportedDual Channel
Form FactorMicro ATX

Questions about this item

Will the four DDR4 slots need individual stick replacement if one fails?

Each of the four DDR4 slots operates independently, so a single faulty module can be swapped without replacing the others.

What memory speed ceiling appears first when all four slots are populated under sustained load?

With four modules installed the board is rated for 2DPC 2R at 2133, 2666 or 2933 MHz JEDEC, so 2933 MHz is the highest guaranteed speed.

How loud or hot does the chipset area get during all-day operation?

The Intel Z490 chipset is passively cooled; typical sustained workloads keep it within normal operating temperature without adding audible fan noise.
