Green micro-ATX board with black heatsinks and red accents, LGA 1150 socket, four DDR3 slots, two long PCIe slots

MSI

MSI Z87M Gaming LGA 1150 Intel Z87 Micro ATX 32GB DDR3 motherboard

SKU CH-SFGH-BYWVJ

Micro ATX board for LGA 1150 CPUs with Intel Z87 chipset, dual-channel DDR3 up to 3000 MHz, 32 GB max, two PCIe 3.0 x16 slots, six SATA III ports, Realtek ALC1150 7.1 audio and Killer E2205 LAN

  • CPU Socket TypeLGA 1150
  • CPU Type4th Gen Intel Core ™ i7/Core ™ i5/Core ™ i3/Pentium/Celeron
  • ChipsetIntel Z87
  • Memory StandardSupports dual-channel DDR3 3000 (overclocking)/2800/2666/260
  • Maximum Memory Supported32GB
  • PCI Slots2 x PCIe 3.0 x16 slots 2 x PCIe 2.0 x1 slots
  • Supports up to 32GB DDR3 memory for high-capacity multitasking
  • Dual PCIe 3.0 x16 slots enable multi-GPU configurations
  • Killer E2205 LAN controller provides low-latency networking
  • Realtek ALC1150 codec delivers 7.1 channel high-definition audio
  • 6 USB 3.0 ports offer fast peripheral connectivity

Compact Z87 board for 4th-gen Intel builds

This Micro ATX motherboard uses the Intel Z87 chipset and an LGA 1150 socket to support 4th generation Core i7, i5, i3, Pentium and Celeron processors. It fits smaller cases while keeping the overclocking features of the Z87 platform. Dual-channel DDR3 memory scales up to 32 GB across a wide range of speeds.

Standard thermals with discrete audio and LAN

The board relies on the CPU cooler and case airflow for thermal management, so noise and power draw follow the chosen processor and enclosure. A Realtek ALC1150 codec delivers 7.1 channel audio with S/PDIF output. A Killer E2205 Gigabit LAN controller handles wired networking.

32 GB DDR3 ceiling decides upgrade scope

Maximum memory capacity is 32 GB, which limits the total RAM you can install regardless of module density. Four slots accept speeds from 1066 MHz up to 3000 MHz when overclocked. If your workload needs more than 32 GB, this board cannot meet it.

Highlights

  • Supports up to 32GB DDR3 memory for high-capacity multitasking
  • Dual PCIe 3.0 x16 slots enable multi-GPU configurations
  • Killer E2205 LAN controller provides low-latency networking
  • Realtek ALC1150 codec delivers 7.1 channel high-definition audio
  • 6 USB 3.0 ports offer fast peripheral connectivity

Specifications

BrandMSI
SeriesMSI Z87M GAMING
ModelMSI Z87M GAMING
CPU Socket TypeLGA 1150
CPU Type4th Gen Intel Core ™ i7/Core ™ i5/Core ™ i3/Pentium/Celeron processors with LGA 1150 architecture
ChipsetIntel Z87
Memory StandardSupports dual-channel DDR3 3000 (overclocking)/2800/2666/2600/2400/2200/2133/2000/1866/1600/1333/1066MHz memory
Maximum Memory Supported32GB
PCI Slots2 x PCIe 3.0 x16 slots
2 x PCIe 2.0 x1 slots
SATA RAID6XSATA III interface
Audio ChipsetRealtek ALC1150 Codec
- 7.1 channel high-quality sound effects
- Supports S/PDIF output
LAN Chipset1 Killer E2205 Gigabit LAN Controller *
Onboard USBIntel Z87 Express Chipset
- 6 USB 3.0 ports (4 on the backplane, 2 supported through built-in USB connectors)
- 6 USB 2.0 ports (2 on the backplane, 4 supported through built-in USB connectors)
RENESAS UPD720202 chipset
- 2 USB 3.0 ports (backplane)

Questions about this item

How do I install the CPU into the LGA 1150 socket without bending the pins?

Lift the socket lever, align the processor triangle with the socket corner, set the chip in place without pressure, then lower and lock the lever; the common mistake is forcing the CPU before the lever is fully open.

Which onboard component will need replacement first during the board's lifespan?

The included CMOS battery supplies the real-time clock and BIOS settings; when the system starts losing time or reverting to defaults, swap the coin cell.

At what memory speed does the DDR3 controller hit its validated ceiling under sustained load?

The highest officially supported DDR3 frequency is 3000 MHz when overclocked; sustained operation at that speed depends on memory quality and cooling.
