Green M.2 2280 circuit board with black controller and silver NAND chips

Mushkin Enhanced

Mushkin Enhanced Helix-L MKNSSDHL250GB-D8 250GB internal SSD

SKU CH-48AS-BCG0Z MPN MKNSSDHL250GB-D8

M.2 2280 250GB PCIe NVMe 1.3 drive with 3D TLC, 2010 MBps read, 1250 MBps write, 200000 read IOPS, 260000 write IOPS and MEDS data protection

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity250GB
  • Memory Components3D TLC
  • InterfacePCIe Gen3 x4 NVMe 1.3
  • Up to 2010 MBps sequential read speeds accelerate large-file workflows
  • Up to 1250 MBps sequential write speeds shorten project save times
  • 200,000 random read IOPS deliver snappy application launches
  • 260,000 random write IOPS keep multitasking responsive
  • 1,500,000-hour MTBF rating backs long-term reliability

M.2 2280 NVMe drive for consumer builds

The Helix-L MKNSSDHL250GB-D8 is a 250GB internal SSD built on 3D TLC flash with a Silicon Motion SM2263XT controller. It targets everyday computing workloads in laptops, ultrabooks and desktops that need responsive storage without enterprise cost.

PCIe Gen3 x4 slot required for full speed

The drive plugs directly into an M.2 2280 key-M socket wired for PCIe Gen3 x4, delivering up to 32 Gbps of bus bandwidth. No cables or drive bays are needed, freeing internal space and simplifying cable routing in compact chassis.

Steady throughput under sustained load

Sequential reads reach 2010 MBps and writes 1250 MBps while random performance holds at 200000 read IOPS and 260000 write IOPS. Active power draw stays at 4.5W with idle at 0.3W, and the controller supports L1.2 low-power state for thermal stability during long sessions.

Highlights

  • Up to 2010 MBps sequential read speeds accelerate large-file workflows
  • Up to 1250 MBps sequential write speeds shorten project save times
  • 200,000 random read IOPS deliver snappy application launches
  • 260,000 random write IOPS keep multitasking responsive
  • 1,500,000-hour MTBF rating backs long-term reliability

Specifications

BrandMushkin Enhanced
SeriesHelix-L
ModelMKNSSDHL250GB-D8
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity250GB
Memory Components3D TLC
InterfacePCIe Gen3 x4 NVMe 1.3
ControllerSilicon Motion SM2263XT
Max Sequential ReadUp to 2010 MBps
Max Sequential WriteUp to 1250 MBps
4KB Random ReadUp to 200,000 IOPS
4KB Random WriteUp to 260,000 IOPS
Seek Time< 0.1 ms
MTBF1,500,000 hours
FeaturesMEDS (Mushkin Enhanced Data-protection Suite) ensures valuable data is protected
- Built-in LDPC ECC provides the most-powerful data correction level in use today
- End-to-end data path protection
- Data shaping increases endurance
- StaticDataRefresh ensures data integrity
- Global wear-leveling evens program/erase counts across data blocks to extend lifespan
Host Memory Buffer (HMB) supported (OS/driver support required)
SLC caching accelerates burst performance
L1.2 power mode support for ultra-low power consumption
NVMe Security Erase support
NVMe Deallocate function support (NVM
Power Consumption (Idle)0.3W
Power Consumption (Active)4.5W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1500G
Height3.80mm
Width22.00mm
Depth80.00mm
Weight7.00g
Shipping weight0.03 kg
Package size131 × 93 × 3 mm

Questions about this item

What sequential-write speed does the 250 GB Helix-L sustain before its SLC cache fills?

The drive writes at up to 1250 MBps while the SLC cache is active; after the cache fills the native 3D TLC speed will be lower.

How much heat and power does the SSD produce during all-day workloads?

Active power draw is 4.5 W and the operating range is 0 °C to 70 °C; the controller supports L1.2 low-power mode to reduce heat when idle.

Which motherboard slot and protocol are required for this M.2 2280 drive?

A motherboard with an M.2 2280 slot wired for PCIe Gen3 x4 and NVMe 1.3 is needed; a SATA-only M.2 slot will not work.
