Small rectangular M.2 2242 SSD with copper-coloured heat-spreader label

Mushkin Enhanced

Mushkin Enhanced MKNSSDVL512GB-D4 internal SSD

SKU CH-13MM-4T5H7 MPN MKNSSDVL512GB-D4

A compact M.2 2242 NVMe drive with 512GB capacity, PCIe Gen4 x4 interface, up to 4725 MBps read and 2225 MBps write speeds.

  • Used ForConsumer
  • Form FactorM.2 2242
  • Capacity512GB
  • Memory ComponentsNAND FLASH
  • InterfacePCIe Gen4 x4NVMe 1.4
  • ProtocolNVMe 1.4

Options 512GB

  • 2TB
  • 1TB
  • 512GB

Struck-through versions exist but are not stocked here.

  • Up to 4725 MB/s sequential read for fast boot and load times
  • Up to 2225 MB/s sequential write for quick file saves and transfers
  • 500 TBW endurance rating for long-term data reliability
  • 5 million hours MTBF for dependable operation
  • M.2 2242 form factor fits space-constrained laptops and small-form-factor PCs

M.2 2242 form factor

This Mushkin Enhanced Vortex LX redline SSD uses the M.2 2242 form factor and connects through a PCIe Gen4 x4 interface with NVMe 1.4 protocol. It provides 512GB of capacity for operating systems, applications and games. The InnoGrit IG5220 controller manages 3D NAND flash with SLC caching and HMB technology.

Suits compact builds; not for 2242-incompatible

The 42mm length fits laptops, small-form-factor desktops and embedded systems that accept 2242 drives. Buyers whose motherboards or enclosures only support longer modules must choose a different length. Operating range is 0°C to 70°C with a 1.5 million-hour MTBF rating.

500TB endurance rating

The 512GB model is rated for 500TB written, which is the double of the 250TB figure shown for this capacity in the manufacturer highlights. Sequential speeds reach up to 4725MBps read and 2225MBps write. A pre-installed carbon nano composite copper foil heat-spreader helps sustain performance.

Highlights

  • Up to 4725 MB/s sequential read for fast boot and load times
  • Up to 2225 MB/s sequential write for quick file saves and transfers
  • 500 TBW endurance rating for long-term data reliability
  • 5 million hours MTBF for dependable operation
  • M.2 2242 form factor fits space-constrained laptops and small-form-factor PCs

Specifications

BrandMushkin Enhanced
SeriesVortex LX redline
ModelMKNSSDVL512GB-D4
Used ForConsumer
Form FactorM.2 2242
Capacity512GB
Memory ComponentsNAND FLASH
InterfacePCIe Gen4 x4NVMe 1.4
ProtocolNVMe 1.4
ControllerInnoGrit IG5220
Max Sequential ReadUp to 4725 MBps
Max Sequential WriteUp to 2225 MBps
Terabytes Written (TBW)500TB
MTBF1,500,000 hours
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Height3.80mm
Width42mm
Depth22mm
Weight7g
Shipping weight0.02 kg
Package size131 × 99 × 13 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does my motherboard need an M.2 2242 slot with PCIe Gen4 x4 support for this drive?

Yes, the drive is an M.2 2242 form factor using a PCIe Gen4 x4 NVMe 1.4 interface, so the motherboard must provide that slot and protocol.

Will it run at full speed in a PCIe Gen3 M.2 slot I already have?

It will operate in a Gen3 slot but sequential reads and writes will be limited to the Gen3 bandwidth ceiling, below the rated 4725 MBps read and 2225 MBps write.

How can I verify the drive is healthy and performing at its rated 4725 MBps read speed after installation?

Check S.M.A.R.T. attributes for health status and run a sequential read benchmark such as CrystalDiskMark to confirm speeds near the rated 4725 MBps.
