Green printed circuit board with black controller and silver label, M.2 2280 form factor

Mushkin Enhanced

Mushkin Enhanced Vortex-LX 2TB M.2 2280 internal SSD MKNSSDVL2TB-D8

SKU CH-583E-T09B1 MPN MKNSSDVL2TB-D8

A 2 TB M.2 2280 NVMe drive with PCIe 4.0 x4, up to 4985 MB/s read, 4775 MB/s write, 275000 random read IOPS, 475000 random write IOPS, and 1500000-hour MTBF

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory Components3D NAND
  • InterfacePCI-Express 4.0 x4

Options 2TB

  • Up to 4985 MB/s sequential read speeds for fast system responsiveness
  • Up to 4775 MB/s sequential write speeds to handle large file transfers quickly
  • 275,000 random read IOPS and 475,000 random write IOPS for snappy multitasking performance
  • 1,500,000 hours MTBF rating indicating long-term reliability
  • PCIe 4.0 x4 NVMe 1.4 interface with HMB and SLC caching for efficient data handling

Vortex-LX 2TB PCIe 4.0 x4 NVMe Drive

The Mushkin Enhanced Vortex-LX is a 2TB internal solid-state drive built for consumer PCs and laptops. It uses a PCI-Express 4.0 x4 interface with NVMe 1.4 protocol and an InnoGrit IG5220 controller. 3D NAND memory delivers sequential reads up to 4985 MB/s and writes up to 4775 MB/s.

Straightforward M.2 2280 Installation

The drive fits a standard M.2 2280 slot and requires only a single screw to secure it. No cables or drive bays are involved. The most common issue is inserting the module at the wrong angle or not fully seating it before tightening the screw, which prevents detection.

Verify Motherboard Slot and BIOS Support

Confirm your motherboard or laptop has an M.2 slot wired for PCIe 4.0 x4 to reach the rated speeds; older PCIe 3.0 slots will work but limit throughput. Check that the system BIOS is current and set to NVMe mode so the drive appears as a bootable device.

Highlights

  • Up to 4985 MB/s sequential read speeds for fast system responsiveness
  • Up to 4775 MB/s sequential write speeds to handle large file transfers quickly
  • 275,000 random read IOPS and 475,000 random write IOPS for snappy multitasking performance
  • 1,500,000 hours MTBF rating indicating long-term reliability
  • PCIe 4.0 x4 NVMe 1.4 interface with HMB and SLC caching for efficient data handling

Specifications

BrandMushkin Enhanced
SeriesVortex-LX
ModelMKNSSDVL2TB-D8
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
Memory Components3D NAND
InterfacePCI-Express 4.0 x4
ProtocolNVMe 1.4
ControllerInnoGrit IG5220
Max Sequential ReadUp to 4985 MB/s
Max Sequential WriteUp to 4775 MB/s
4KB Random ReadUp to 275,000 IOPS
4KB Random WriteUp to 475,000 IOPS
MTBF1,500,000 hours
Shipping weight0.01 kg
Package size178 × 127 × 18 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How can I verify the Vortex-LX 2TB is delivering the rated 4985 MB/s sequential read after installation?

Run a benchmark such as CrystalDiskMark on an empty drive using the NVMe protocol; the sequential read result should approach 4985 MB/s when the drive is connected to a PCIe 4.0 x4 slot.

What ships with the MKNSSDVL2TB-D8 and what must I supply myself?

The box contains only the M.2 2280 drive; you must provide a compatible motherboard or laptop slot, a retaining screw, and any desired heatsink.

Which capacity should I choose if I need the 4775 MB/s sequential write figure shown for this model?

The 2TB capacity listed here is the one rated for 4775 MB/s sequential write; other capacities have different specifications.
