Small green PCB with 24-pin ATX plug, 4+4 CPU, SATA, IDE and DC jack, short cables attached

myVolts

myVolts LD-A160WL 12V 160W DC-ATX power supply

SKU CH-9F40-SJJTJ MPN LD-A160WL

Direct-plug 12 V DC-ATX board delivers 160 W through ATX24, CPU4+4, SATA, IDE and DC5525 connectors with over-current and short-circuit protection

  • TypeAT
  • Direct motherboard power via 24-pin ATX connector eliminates 24 wires
  • Compact design fits ITX and HTPC cases while delivering 160 W
  • Overcurrent protection shuts down output when maximum current is reached
  • circuit protection turns off power instantly during a fault
  • Multiple rails provide +5 VSB at 2 A, +5 V at 6 A, +3.3 V at 6 A, +12 V at 8 A

Compact DC-ATX board for 12 V systems

The myVolts LD-A160WL plugs straight into a 24-pin ATX socket and delivers 160 W from a single 12 V source. It removes the bulk of a standard PSU and the tangle of 24 wires, making it a tidy fit for thin Mini-ITX builds, HTPC cases or embedded appliances.

Suited to space-constrained 12 V builds.

Builders powering a low-draw board from a 12 V brick or battery will appreciate the direct ATX connection and short cables. Systems that require mains input, higher wattage or multiple PCIe power connectors must use a conventional ATX supply instead.

160 W total from a 12 V DC input

The board accepts 12 V and regulates five rails: +12 V at 8 A, +5 V at 6 A, +3.3 V at 6 A, +5 VSB at 2 A and -12 V at 0.15 A. Over-current and short-circuit protection shut the outputs down when limits are exceeded.

Highlights

  • Direct motherboard power via 24-pin ATX connector eliminates 24 wires
  • Compact design fits ITX and HTPC cases while delivering 160 W
  • Overcurrent protection shuts down output when maximum current is reached
  • circuit protection turns off power instantly during a fault
  • Multiple rails provide +5 VSB at 2 A, +5 V at 6 A, +3.3 V at 6 A, +12 V at 8 A

Specifications

TypeAT

Questions about this item

What comes in the box and what else is needed to run the LD-A160WL?

The box includes the board with ATX 24-pin, CPU 4+4-pin, SATA, IDE and DC 5525 connectors plus cables up to 320 mm. You must supply a 12V DC source such as an external brick or battery.

How do I pick between the listed voltage rails for my build?

The board delivers fixed rails of +12V/8A, +5V/6A, +3.3V/6A, +5VSB/2A and -12V/0.15A simultaneously; choose a 12V source that can provide at least 160W total.

What does the 160W rating mean once the board is installed in a Mini-ITX or HTPC system?

It is the combined maximum output across all rails; the +12V rail supplies up to 8A, the +5V and +3.3V rails each supply up to 6A, and the +5VSB rail supplies up to 2A, with over-current and short-circuit shutdown.
