Green PCB power module with ATX24Pin and CPU4Pin connectors, multiple SATA and IDE cables, DC5525 jack, compact rectangular shape

myVolts

myVolts LD-NAS200L 12V 200W heat resistant HTPC power supply

SKU CH-0G0C-MRP6J MPN LD-NAS200L

A 12 V 200 W ATX power module plugs directly into the motherboard, saving space in HTPC or ITX builds while delivering 12 A on the 12 V rail and 10 A on 5 V

  • TypeAT
  • Saves case space with direct ATX motherboard plug-in
  • Eliminates 24 wires by connecting straight to the ATX connector
  • Premium PCB material handles high heat at 12V 200W output
  • Over-current and short-circuit protection shuts down output on fault
  • Powers MINI PCs, HTPC, POS, ITX cases, servers and industrial systems

Direct-plug ATX module for compact builds

The myVolts LD-NAS200L is a 12V 200W power adapter board that connects straight to the motherboard ATX connector. It removes 24 individual wires to save space inside small cases. Premium PCB material provides high heat resistance for dependable operation. Over-current and short-circuit protection shut the output down when peak current is reached or a short occurs.

Suits HTPC and industrial systems.

This module fits MINI computers, HTPC builds, POS machines, ITX cases, network servers and industrial control systems that run from a 12V source. Builders who need more than 200W total power or additional PCIe connectors for discrete graphics cards should look at something else. Systems requiring ATX-form-factor PSUs with internal cooling fans are also outside its scope.

12V DC input with 200W distributed across five rails

The board accepts a single 12V DC supply through a 5525 jack and delivers +12V at 12A, +5V at 10A, +3.3V at 8A, +5VSB at 2A and -12V at 0.05A. An IC oscillator runs at 250-350 kHz with a 0.8V reference. Cables include 320mm DC, 210mm CPU4Pin, 200mm IDE, 150mm SATA and a 24-pin ATX plug.

Highlights

  • Saves case space with direct ATX motherboard plug-in
  • Eliminates 24 wires by connecting straight to the ATX connector
  • Premium PCB material handles high heat at 12V 200W output
  • Over-current and short-circuit protection shuts down output on fault
  • Powers MINI PCs, HTPC, POS, ITX cases, servers and industrial systems

Specifications

TypeAT

Questions about this item

How do I install the LD-NAS200L and which step is often missed?

Plug the 24-pin ATX connector directly into the motherboard, then attach the CPU 4-pin, up to four SATA, two IDE and the DC5525 jack; the step often missed is connecting the separate CPU 4-pin cable after the main board is seated.

What maintenance or replacement will the LD-NAS200L need later?

The unit has no user-serviceable parts; if over-current or short-circuit protection trips, disconnect the DC5525 input for a few seconds to reset the board, otherwise no routine maintenance is required.

Which limit appears first under sustained load on the LD-NAS200L?

The +12 V rail is rated at 12 A; when sustained draw reaches that peak the over-current protection will shut the output off before any other rail hits its maximum.
