Pink aluminium enclosure, terminal strip, fan vent, 24V 15A 360W label

myVolts

myVolts Reliable Radio S-360-24 24V 15A 360W power supply pink

SKU CH-JXRJ-EXX55

A 24 V, 15 A switch-mode power supply with overload, over-voltage and short-circuit protection for industrial and radio equipment

  • TypeAT
  • Reliable operation in cold environments down to 0 °C
  • High efficiency with low DC ripple for clean power
  • Excellent insulation strength protects connected equipment
  • 100 % full-load burn-in test ensures dependable output
  • circuit, overload and over-voltage protection built in

24V 15A switch-mode supply for radio and automation

This pink aluminium-cased unit delivers 360W of regulated DC power from AC110V or AC220V mains with a ±15% tolerance. It is aimed at engineers and hobbyists running industrial automation, LED displays, CCTV, 3D printers or radio equipment that require a steady 24V rail. The built-in voltage-adjust terminal allows fine tuning of the output to suit specific load requirements.

Thermal behaviour and protection

The supply operates from 0°C to 40°C ambient and is rated for up to 95% non-condensing humidity, relying on natural convection through the aluminium housing rather than a fan. Overload, over-voltage and short-circuit protection circuits shut the output down safely when limits are exceeded, and a 100% full-load burn-in at the factory verifies long-term reliability. Low DC ripple and high working efficiency keep waste heat low during continuous operation.

Build integration

Screw terminals labelled L and N accept the AC input, while GND and V provide the DC output; an additional ADJ terminal gives access to the voltage adjustment. The compact footprint of approximately 85mm by 58mm by 33mm leaves room in tight enclosures and the lightweight aluminium chassis simplifies DIN-rail or panel mounting. CCC, FCC and CE markings confirm compliance for use in commercial and industrial installations.

Highlights

  • Reliable operation in cold environments down to 0 °C
  • High efficiency with low DC ripple for clean power
  • Excellent insulation strength protects connected equipment
  • 100 % full-load burn-in test ensures dependable output
  • circuit, overload and over-voltage protection built in

Specifications

TypeAT

Questions about this item

How do I wire the AC input and DC output on the S-360-24, and which terminal is often mixed up?

Connect live and neutral to L and N for AC 110 or 220 V input; link GND to the negative DC rail and V to the positive 24 V rail — the ADJ terminal is only for voltage trim and is frequently mistaken for a second output

What maintenance will this 360 W unit need after extended operation?

No scheduled servicing is required; the aluminium chassis relies on natural convection, so keep the vents clear of dust and verify the fan-less cooling path remains unobstructed

At what ambient temperature does the supply hit its thermal limit during continuous 15 A load?

The rated operating range tops out at 40 °C; above that the internal protection will curtail output to prevent overheating
