Open-frame PCB power supply, green board, dual output terminals, compact 4 by 2 inch footprint

myVolts

myVolts RPD-60A 60W dual output power supply 5V 12V 24V

SKU CH-A030-0AFTX

Dual-output 60 W medical-grade supply delivering 5 V and 12 V or 24 V with 2×MOPP safety approval and free-air convection cooling

  • TypeAT
  • Medical-grade 2×MOPP compliance meets strict patient-safety standards
  • Dual 5 V/12 V or 5 V/24 V outputs power two rails from one compact 4″×2″ PCB
  • 90–264 VAC universal input works worldwide without a selector switch
  • Extremely low leakage current under 150 µA suits BF-type medical applications
  • Built-in short-circuit, overload and over-voltage protections guard connected equipment

Dual-output medical power supply

The myVolts RPD-60A delivers 60 W from a 4" x 2" open-frame PCB. It provides two regulated outputs: 5 V at 5.5 A with 12 V at 2.2 A, or 5 V at 3.85 A with 24 V at 1.65 A. The unit meets 2 x MOPP medical safety standards and suits devices such as oral irrigators, hemodialysis machines and sleep apnea equipment.

Verify input voltage and output combination

Confirm your system operates within the 90–264 V AC input range before installation. Select the required dual-output set — either 5 V/12 V or 5 V/24 V — to match the load specifications of your medical device. Ensure the chassis can accommodate the 4" x 2" footprint and that free-air convection cooling is sufficient for the enclosure.

Continuous convection-cooled operation

Rated for full 60 W output with no forced airflow, the supply relies on natural convection for thermal management. Protections against short circuit, overload and over-voltage engage automatically during sustained loads. Leakage current remains below 150 µA, and compliance with EMC standard BS EN/EN55011 supports stable long-term performance in medical environments.

Highlights

  • Medical-grade 2×MOPP compliance meets strict patient-safety standards
  • Dual 5 V/12 V or 5 V/24 V outputs power two rails from one compact 4″×2″ PCB
  • 90–264 VAC universal input works worldwide without a selector switch
  • Extremely low leakage current under 150 µA suits BF-type medical applications
  • Built-in short-circuit, overload and over-voltage protections guard connected equipment

Specifications

TypeAT

Questions about this item

What comes in the box and do I need to buy cables or a case separately?

The unit is supplied as an open-frame PCB measuring 4 by 2 inches with no enclosure, cables or mounting hardware included. You will need to source a suitable chassis, wiring and connectors for your installation.

Should I choose the 5 V plus 12 V version or the 5 V plus 24 V version?

The RPD-60A provides both output pairs simultaneously: 5 V at up to 5.5 A together with 12 V at up to 2.2 A, and 5 V at up to 3.85 A together with 24 V at up to 1.65 A. Select the rails your load requires; both are available on the same board.

What does the 60 W rating mean when the supply is installed in my equipment?

The 60 W rating is the total continuous output power across both dual-output channels combined, delivered with free-air convection cooling and an input range of 90 to 264 VAC.
