Rectangular aluminium power supply, silver finish, screw terminals visible

myVolts

myVolts S-60-12 12V 5A 60W power supply

SKU CH-9327-5PFT1

A 12V 5A switch-mode supply with short-circuit, overload and overvoltage protection for industrial automation, LED displays, CCTV and 3D printers

  • TypeAT
  • High efficiency with low DC ripple for stable output
  • circuit, overload and over-voltage protection built in
  • Operates from 0 °C to 40 °C for industrial use
  • 100 % full-load burn-in test ensures reliability
  • Wide AC 100-240 V input suits global installations

Industrial 12V power supply

The myVolts S-60-12 delivers 12V at 5A for a total of 60W from an AC100-240V source. It suits industrial automation, LED displays, CCTV, 3D printers and similar DC12V equipment. An aluminium alloy case gives high insulation strength and the unit has passed a full-load burn-in test. Protection covers short circuit, overload and overvoltage conditions.

Wiring and integration

Input terminals accept live and neutral on L and N; output uses GND for negative and V for positive with an ADJ point for voltage trim. Natural convection cooling means no fan noise and no moving parts to fail. The supply fits alongside other DIN-rail or panel-mounted gear where a compact 60W 12V source is required. It frees the builder from sourcing a separate AC-DC module for each low-voltage subsystem.

Thermals and efficiency

Rated for 0 to 40°C ambient operation and storage from -20 to 60°C at up to 95% non-condensing humidity. High working efficiency and low DC ripple keep waste heat low during continuous load. The aluminium housing acts as the heatsink so the unit runs silently. CCC, FCC and CE markings confirm compliance for industrial and commercial environments.

Highlights

  • High efficiency with low DC ripple for stable output
  • circuit, overload and over-voltage protection built in
  • Operates from 0 °C to 40 °C for industrial use
  • 100 % full-load burn-in test ensures reliability
  • Wide AC 100-240 V input suits global installations

Specifications

TypeAT

Questions about this item

What is the maximum operating temperature before the S-60-12 hits its thermal limit?

The unit is rated for continuous operation up to 40 °C ambient; beyond that the internal protection may reduce output or shut down to prevent overheating.

How loud and hot does the S-60-12 get when run at full load all day?

It uses natural convection cooling with no fan, so it runs silently; the aluminium alloy case will become warm to the touch at 60 W load but stays within the 0–40 °C operating range.

Which cables or connectors must I already have to wire the S-60-12 into my 12 V device?

You need supply wires for the AC input terminals labelled L and N (100–240 V) and DC leads for the V+ and GND output terminals; no mains lead or DC plug is included.
