Rectangular bench power supply unit with dual digital displays and front panel controls

myVolts

myVolts STP6005D DC power supply 0-60V 0-5A factory maintenance

SKU CH-5D4F-48JAJ MPN STP6005D

Adjustable 0-60 V, 0-5 A DC supply with dual display, CV/CC auto-switching and short-circuit, over-temperature protection for bench and cabinet use

  • TypeAT
  • Continuous 0-60V and 0-5A adjustment for flexible bench testing
  • Automatic CV/CC crossover keeps output stable when load conditions change
  • Dual independent displays show voltage and current at a glance
  • Built-in current-limiting, short-circuit and over-temperature protection guards connected gear
  • Up to 80% efficiency reduces waste heat during extended maintenance sessions

Adjustable DC output 0-60 V 0-5 A

The myVolts STP6005D is a bench-top DC power supply that delivers continuously adjustable voltage from 0 to 60 V and current from 0 to 5 A. It operates in constant-voltage or constant-current mode with automatic crossover, and the dual display shows both values independently. Efficiency reaches 80 %. It is built for factory maintenance, calibration stations and integration into test cabinets.

Engineers and technicians needing precise

This unit suits engineers and technicians who require a regulated DC source for prototyping, repair or calibration work where fine voltage and current control matter. The 0.5 % + 3 mV line regulation and 50 mVrms ripple support sensitive analogue circuits. Buyers who need higher current, higher voltage, programmable sequencing or remote computer control should look at other equipment.

60 V maximum output voltage

The single specification that decides fit is the 60 V maximum output voltage combined with a 5 A current limit. If the device under test requires more than 60 V or more than 5 A, this supply cannot power it.

Highlights

  • Continuous 0-60V and 0-5A adjustment for flexible bench testing
  • Automatic CV/CC crossover keeps output stable when load conditions change
  • Dual independent displays show voltage and current at a glance
  • Built-in current-limiting, short-circuit and over-temperature protection guards connected gear
  • Up to 80% efficiency reduces waste heat during extended maintenance sessions

Specifications

TypeAT

Questions about this item

At what output current does the load-regulation spec change from 0.1% + 3mV to 0.2% + 5mV?

The load-regulation specification shifts at 3 A; below that it is 0.1% + 3mV, above it becomes 0.2% + 5mV.

What protection features activate during continuous full-load operation to manage heat and faults?

Over-temperature protection, short-circuit protection and current-limiting buck circuitry engage automatically during sustained use.

Which mains fuse must be present in the IEC inlet before the unit will power on?

A 5 A, 250 VAC slow-blow fuse (marked F5AL) is required in the inlet for the supply to operate.
