Silver metal rectangular power supply with screw terminals and voltage selector switch

myVolts

myVolts XC-360-12 12V 20A 360W power supply

SKU CH-VBHE-3FX4N MPN XC-360-12

Converts AC 110V/220V to DC 12V at 20A for 360W output with short-circuit, overload, over-voltage and over-temperature protection in a metal enclosure

  • TypeAT
  • Converts AC 110V/220V to DC 12V 20A 360W
  • Selectable 110V/115V or 220V/230V input with side switch
  • circuit, overload, over-voltage and over-temperature protection built in
  • Metal enclosure with EMI filter for low ripple and noise
  • Operates 0 to 40 °C with up to 95 % non-condensing humidity

12V 20A 360W switched-mode supply

The myVolts XC-360-12 converts AC 110V or 220V input to a regulated DC 12V output rated at 20A continuous. It is built for industrial automation, LED lighting installations, CCTV systems and similar equipment that need a stable 12V rail. The metal enclosure with aluminium base aids heat dissipation during extended operation.

Dual-voltage input with manual selector

The unit accepts AC 110V/115V or 220V/230V at 50/60Hz, but the selector switch on the housing must be set to match the local mains before power is applied. Factory default is the 110V/115V position; switching to the 220V side is required for higher-voltage supplies. Built-in EMI filtering and 13% output-voltage adjustment via the ADJ terminal provide clean power within the specified range.

360W capacity with full protection suite

At 360W the supply comfortably drives LED strips, controllers and instrumentation loads up to the 20A limit. Short-circuit, overload, over-voltage and over-temperature protections shut the output down safely when limits are exceeded. Operating temperature is rated 0°C to 40°C and storage range extends from -20°C to 60°C with up to 95% non-condensing humidity.

Highlights

  • Converts AC 110V/220V to DC 12V 20A 360W
  • Selectable 110V/115V or 220V/230V input with side switch
  • circuit, overload, over-voltage and over-temperature protection built in
  • Metal enclosure with EMI filter for low ripple and noise
  • Operates 0 to 40 °C with up to 95 % non-condensing humidity

Specifications

TypeAT

Questions about this item

Should I choose the 12V 20A 360W model or the 30A variant mentioned in the description?

The product supplied is the XC-360-12 rated at 12V 20A 360W; the 30A figure appears in the supplier title for a different configuration.

What does the 360W rating mean when the unit is installed in my equipment?

It can deliver up to 360W continuously at 12V 20A provided the ambient temperature stays within 0~40°C and cooling is adequate.

How does the AC 110V/220V input selector affect the output I actually get?

A side switch sets the input range to 110V/115V or 220V/230V; the unit ships set to 110V/115V and must be moved to the 220V position before connecting to a 220V supply.
