Full-height single-slot graphics card with silver rear bracket and four DisplayPort connectors

NVIDIA

NVIDIA Quadro M4000 8GB GDDR5 graphics card

SKU CH-JJ7J-RZSJA MPN M4000

Professional GPU with 8 GB GDDR5 memory and four DisplayPort 1.2 outputs for multi-display workstations

  • Memory TypeDDR
  • 8GB GDDR5 memory handles large models and textures
  • Four DisplayPort 1.2 outputs drive up to 4096×2160 each
  • PCI Express 3.0 x16 interface provides 16 lanes of bandwidth
  • Single-slot full-height design fits dense workstation chassis
  • 120W TGP with 6-pin power keeps thermal load manageable

Professional visual computing

The NVIDIA Quadro M4000 is a full-height graphics card built for professional visual computing workloads. It delivers 8GB of GDDR5 memory across a 256-bit bus and connects through a PCI Express 3.0 x16 interface. The card targets users who need reliable multi-display output and certified application stability.

Single-slot workstation fit

A single-slot cooler and included rear bracket allow the card to fit into dense workstation chassis without blocking adjacent expansion slots. Four DisplayPort 1.2 connectors support up to four simultaneous displays at 4096 x 2160 digital resolution. The 120W TGP draws power through a single 6-pin connector, simplifying cable routing in compact builds.

Maxwell architecture limits

The Maxwell architecture provides DirectX 12 and OpenGL 4.5 support for professional software compatibility. Analog output reaches 2048 x 1536 at 85Hz for legacy display connections. Memory bandwidth is defined by the 256-bit GDDR5 interface, setting a fixed ceiling for compute and rendering throughput.

Highlights

  • 8GB GDDR5 memory handles large models and textures
  • Four DisplayPort 1.2 outputs drive up to 4096×2160 each
  • PCI Express 3.0 x16 interface provides 16 lanes of bandwidth
  • Single-slot full-height design fits dense workstation chassis
  • 120W TGP with 6-pin power keeps thermal load manageable

Specifications

Memory TypeDDR

Questions about this item

What bandwidth limit does the PCI Express 3.0 x16 interface impose on this card?

The PCI Express 3.0 x16 link provides up to 16 GT/s raw bandwidth per lane, so the 16-lane slot caps theoretical throughput at the full 3.0 x16 rate for this Maxwell GPU.

What physical clearance and power connector does the full-height single-slot design require?

It needs a full-height PCIe slot, one 6-pin PCIe power cable from the PSU, and enough case depth for a single-slot bracket with four DisplayPort 1.2 outputs.

How is the card installed, and which step do builders often miss?

Seat the card in the x16 slot, secure the rear bracket screw, then attach the 6-pin power connector; the missed step is forgetting that 6-pin cable, leaving the 120 W TGP unsatisfied.
