Green circuit board with black memory chips, no heat spreader, 288 gold pins along bottom edge

OWC

OWC 32GB DDR5 5200 CL42 2Rx8 288-pin 1.1V Non-ECC UDIMM memory upgrade

SKU CH-1J9F-CBM3P

A 32 GB DDR5 5200 CL42 UDIMM upgrade for compatible HP OMEN 25L, 40L and 45L desktops

  • Capacity32GB
  • Type288-Pin DDR5 Non-ECC UDIMM
  • SpeedDDR5 5200 (PC5 41600)
  • CAS LatencyCL42
  • Voltage1.1V
  • ECCNo

Capacity 32GB

  • Boost performance with 32GB DDR5 5200 CL42 upgrade
  • JEDEC and RoHS compliant for warranty-safe installation
  • Low 1.1V voltage reduces system power draw
  • 2Rx8 dual-rank design increases memory density
  • Compatible with OMEN 25L, 40L and 45L desktops

OWC 32GB DDR5 5200 UDIMM Upgrade

This 32GB DDR5 5200 CL42 module is a system-specific upgrade for select HP OMEN desktops. It operates at 1.1V as a non-ECC unbuffered DIMM with a 2Rx8 rank configuration and no heat spreader. The single 288-pin stick is built to JEDEC standards for warranty-safe installation.

Suits owners of listed OMEN 25L 40L 45L models

Buyers with HP OMEN 25L GT15-1075t or GT15-2085t, 40L GT21-1490xt or GT21-2085t, and 45L GT22-1455xt can install this directly. Systems needing ECC registered memory or lower voltage operation will not be compatible with this unbuffered non-ECC design.

32GB single module at DDR5 5200 CL42

The 32GB capacity on one 288-pin stick at 5200MHz CL42 determines if this matches the required density and speed for the target platform. Verify the motherboard accepts a 2Rx8 rank unbuffered module before purchase.

Highlights

  • Boost performance with 32GB DDR5 5200 CL42 upgrade
  • JEDEC and RoHS compliant for warranty-safe installation
  • Low 1.1V voltage reduces system power draw
  • 2Rx8 dual-rank design increases memory density
  • Compatible with OMEN 25L, 40L and 45L desktops

Specifications

BrandOWC
Part Number5U2D52R832GB
Capacity32GB
Type288-Pin DDR5 Non-ECC UDIMM
SpeedDDR5 5200 (PC5 41600)
CAS LatencyCL42
Voltage1.1V
ECCNo
Buffered/RegisteredUnbuffered
Rank2Rx8
Heat SpreaderNo
Compatible SystemHP OMEN 25L GT15-1075t
HP OMEN 25L GT15-2085t
HP OMEN 40L GT21-1490xt
HP OMEN 40L GT21-2085t
HP OMEN 45L GT22-1455xt

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I choose the single 32GB DDR5 5200 module or add a second identical stick for dual-channel on my OMEN 45L GT22-1455xt?

The kit is a single 32GB DDR5 5200 CL42 2Rx8 UDIMM; adding a second matching module enables dual-channel bandwidth on the OMEN 45L GT22-1455xt.

What does the 5200 MT/s rating deliver once installed in an OMEN 25L GT15-1075t?

The module runs at JEDEC-standard 5200 MT/s CL42 at 1.1V, giving the OMEN 25L GT15-1075t the rated DDR5 bandwidth without overclocking.

How does the 288-pin DDR5 UDIMM interface limit speed on the OMEN 40L GT21-2085t?

The 288-pin unbuffered DDR5 interface caps operation at the JEDEC 5200 MT/s CL42 specification on the OMEN 40L GT21-2085t.
