Green rectangular SODIMM circuit board with black memory chips and gold edge contacts

OWC

OWC 5S6D52R832GB 32GB DDR5 5600 CL46 2Rx8 1.1V SODIMM memory upgrade

SKU CH-YM1Z-B00RP

32 GB DDR5 5600 CL46 SODIMM upgrade for select Lenovo ThinkPad laptops

  • Capacity32GB
  • Type262-Pin DDR5 Non-ECC SODIMM
  • SpeedDDR5 5600 (PC5 44800)
  • CAS LatencyCL46
  • Voltage1.1V
  • ECCNo

Capacity 32GB

  • 32GB capacity expands multitasking headroom for demanding workloads
  • DDR5 5600 speed delivers high bandwidth for faster data throughput
  • CL46 latency and 1.1V voltage balance responsive timing with efficient power use
  • 262-pin SODIMM form factor fits compatible Lenovo ThinkPad laptops directly
  • JEDEC and RoHS compliance ensures warranty-safe, standards-based upgrade

32GB DDR5 SODIMM for ThinkPad E14 Gen 6 E16 Gen 2

This module is a single 32GB DDR5 5600 CL46 2Rx8 1.1V SODIMM designed for the listed Lenovo ThinkPad models. It replaces Lenovo part 4X71M23189 and meets JEDEC PC5-44800 specifications. Buyers needing ECC or registered memory cannot use this unbuffered non-ECC stick.

262-pin SODIMM installs in minutes with basic tools

The stick slots into the standard 262-pin socket found in each compatible ThinkPad. No heat spreader is present, so clearance is minimal. The most common issue is seating the module fully until the side clips click; a partial insert causes a no-post condition. Static precautions are advised.

Verify your ThinkPad model

Confirm the exact model name matches E14 Gen 6, E16 Gen 2, P1 Gen 6 or P16v Gen 1. Check how many SODIMM sockets your unit has and whether one is already occupied. Systems limited to 32GB total will not benefit from adding a second module.

Highlights

  • 32GB capacity expands multitasking headroom for demanding workloads
  • DDR5 5600 speed delivers high bandwidth for faster data throughput
  • CL46 latency and 1.1V voltage balance responsive timing with efficient power use
  • 262-pin SODIMM form factor fits compatible Lenovo ThinkPad laptops directly
  • JEDEC and RoHS compliance ensures warranty-safe, standards-based upgrade

Specifications

BrandOWC
Part Number5S6D52R832GB
Capacity32GB
Type262-Pin DDR5 Non-ECC SODIMM
SpeedDDR5 5600 (PC5 44800)
CAS LatencyCL46
Voltage1.1V
ECCNo
Buffered/RegisteredUnbuffered
Rank2Rx8
Heat SpreaderNo
Compatible SystemLenovo ThinkPad E14 Gen 6
Lenovo ThinkPad E16 Gen 2
Lenovo ThinkPad P1 Gen 6
Lenovo ThinkPad P16v Gen 1

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How can I verify the memory is running at 5600 CL46 after installing it in my ThinkPad P1 Gen 6?

Open Task Manager or BIOS and confirm the speed reads 5600 MT/s and the CAS latency shows CL46; the module is a 262-pin DDR5 SODIMM rated at 1.1 V.

What ships in the box and is anything else required for installation?

The box contains one 32 GB DDR5 5600 CL46 2Rx8 262-pin 1.1 V SODIMM module; no extra parts or tools are needed for the upgrade.

Which capacity should I choose if I want a single-module upgrade for a ThinkPad E14 Gen 6?

This part is a single 32 GB module; choose it when you need a 32 GB upgrade for a compatible ThinkPad.
