Two green DDR5 SODIMM modules, 262-pin, no heat spreader

OWC

OWC 64GB (2x32GB) DDR5 5600 CL46 SODIMM for Lenovo ThinkStation P3 Tiny

SKU CH-K006-PJE09

DDR5 SODIMM kit adds 64 GB of CL46 5600 memory to a Lenovo ThinkStation P3 Tiny

  • Capacity64GB (2 x 32GB)
  • Type262-Pin DDR5 Non-ECC SODIMM
  • SpeedDDR5 5600 (PC5 44800)
  • CAS LatencyCL46
  • Voltage1.1V
  • ECCNo

Capacity 64GB (2 x 32GB)

  • 64 GB dual-channel kit expands multitasking headroom
  • DDR5 5600 CL46 speed accelerates data throughput
  • 1 V operation lowers system power draw
  • 262-pin SODIMM form factor fits ThinkStation P3 Tiny
  • JEDEC and RoHS compliant ensures warranty-safe upgrade

64GB DDR5 kit for ThinkStation P3 Tiny

This 64GB kit contains two 32GB DDR5 5600 SODIMM modules built for the Lenovo ThinkStation P3 Tiny. It delivers a straightforward capacity increase for the compact workstation. The unbuffered non-ECC design matches the system's supported memory architecture. Installation follows the standard SODIMM procedure for this platform.

DDR5 5600 CL46 JEDEC limits

The modules operate at the JEDEC-standard DDR5 5600 speed with CL46 latency at 1.1V. This is the baseline specification for DDR5 SODIMM; no higher JEDEC speeds or lower latencies are guaranteed by the standard itself. The 262-pin form factor and 2Rx8 organisation are fixed by the DDR5 SODIMM specification. Overclocking headroom is not defined by JEDEC.

64GB capacity and 2Rx8 headroom

The 64GB total capacity provides ample headroom for large datasets, virtual machines and simultaneous professional applications. Dual-rank 2Rx8 organisation allows the memory controller to interleave accesses across ranks within each module. Systems limited to two SODIMM slots cannot exceed this 64GB total without higher-density modules that may not be qualified.

Highlights

  • 64 GB dual-channel kit expands multitasking headroom
  • DDR5 5600 CL46 speed accelerates data throughput
  • 1 V operation lowers system power draw
  • 262-pin SODIMM form factor fits ThinkStation P3 Tiny
  • JEDEC and RoHS compliant ensures warranty-safe upgrade

Specifications

BrandOWC
Part Number5S6D52R8064P
Capacity64GB (2 x 32GB)
Type262-Pin DDR5 Non-ECC SODIMM
SpeedDDR5 5600 (PC5 44800)
CAS LatencyCL46
Voltage1.1V
ECCNo
Buffered/RegisteredUnbuffered
Rank2Rx8
Heat SpreaderNo
Compatible SystemLenovo ThinkStation P3 Tiny

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I choose the 64 GB kit or buy a single 32 GB module instead?

The kit provides two 32 GB modules for a total of 64 GB, letting the ThinkStation P3 Tiny run in dual-channel mode for higher bandwidth than a single stick.

What does the 5600 MT/s rating deliver in the ThinkStation P3 Tiny?

The modules run at the JEDEC-standard 5600 MT/s with CL46 latency, giving the P3 Tiny its maximum supported memory bandwidth without overclocking.

Is the 262-pin DDR5 SODIMM interface the limiting factor for speed?

Yes, the 262-pin DDR5 SODIMM form factor caps the upgrade at the standard 5600 MT/s / PC5-44800 data rate and 1.1 V operation.
