12.1 inch industrial all-in-one panel PC with resistive touchscreen and fanless aluminium chassis

partaker

Partaker A2-PA-121TPC-CE5B(I76)-8G256G 12.1" all-in-one PC i7-6500U 8GB DDR3 256GB SSD

SKU CH-KMRK-TYCCD

A 12.1" IP65-rated industrial panel PC with a high-temperature 5-wire resistive touchscreen, Intel Core i7-6500U, 8GB DDR3, 256GB SSD, and Windows 11 Pro for continuous operation

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 6th Gen
  • GPU/VGA TypeIntel HD Graphics 520
  • Memory Capacity8GB DDR3
  • SSD256GB

Memory Capacity 8GB DDR3

  • IP65 front panel resists dust and water jets
  • 1 inch 1024 x 768 display with 350 cd/m² brightness
  • Fanless aluminium alloy cooling runs silently
  • Intel Core i7-6500U up to 3.10 GHz with 8 GB DDR3
  • Windows 11 Pro pre-installed for immediate use

Industrial Panel PC with IP65 Front

The Partaker A2 is a 12.1 inch all-in-one computer built for continuous industrial use. Its TFT LED panel carries IP65 front protection and a five-wire resistive touchscreen rated for high-temperature environments. The system ships with Windows 11 Pro 64-bit pre-installed and runs on an Intel Core i7 6500U processor with Intel HD Graphics 520, 8GB DDR3L memory and a 256GB SSD.

Fanless Aluminium Chassis Mounts Four Ways

The unit uses a passive aluminium alloy cooling design with no moving fans, so installation is silent and dust ingress is minimised. It supports embedded, wall-mounted, desktop or cantilevered mounting using the included buckle kits and a 301 x 229 mm cut-out. I/O covers HDMI, VGA, two USB 3.0, two USB 2.0, dual LAN, audio in/out, two COM ports and a 12V DC input. Expandability includes a Mini PCIe slot with a SIM holder for wireless modules.

Sustained Operation from 0 to 50 °C

With the installed SSD the operating range is 0 to 50 °C and 10 to 95 percent humidity non-condensing. The fanless thermal path relies on the aluminium chassis to spread heat, so the i7-6500U maintains its 3.10 GHz boost under prolonged loads without throttling from active cooling failure. The resistive touchscreen is rated for 35 million touches and the backlight for 30,000 hours minimum, supporting round-the-clock shifts in manufacturing, automation or outdoor kiosk roles.

Highlights

  • IP65 front panel resists dust and water jets
  • 1 inch 1024 x 768 display with 350 cd/m² brightness
  • Fanless aluminium alloy cooling runs silently
  • Intel Core i7-6500U up to 3.10 GHz with 8 GB DDR3
  • Windows 11 Pro pre-installed for immediate use

Specifications

ModelA2-PA-121TPC-CE5B(I76)-8G256G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 6th Gen
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity8GB DDR3
SSD256GB
HDDNo
Screen Size12.1"
TouchscreenYes

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How can I verify the IP65 front panel and 5-wire resistive touchscreen are functioning after installation?

Confirm the front panel meets IP65 rating by checking for dust and water jet resistance, then test touch response across the 12.1" screen at the 1024 x 768 resolution; the resistive layer should register 35 million touches minimum.

What accessories are included in the packing list and which expansion parts must be sourced separately?

The box contains the Partaker A2 Panel PC, a power supply, and a power cord; WiFi or 4G modules for the Mini PCIe slot and a SIM card are not included and must be purchased separately.

Which memory and storage configuration suits an upgrade to the 16 GB DDR3L maximum and additional NVMe or SATA drives?

The unit ships with 8 GB DDR3L-1600 in two SODIMM slots and a 256 GB mSATA SSD; add two 8 GB DDR3L modules to reach 16 GB, and use the M.2 2280 slot for NVMe PCIe x4 or SATA SSD, plus the 2.5" bay for another SATA drive.
