Silver 12.1 inch industrial panel PC with resistive touchscreen and aluminium fanless housing

partaker

partaker A2-PA-121TPC-CE5B(J19)-4G64G 12.1" industrial panel PC

SKU CH-G45S-VXPQJ

A 12.1 inch IP65 front panel PC with Intel Celeron J1900, 4 GB DDR3L, 64 GB mSATA SSD, resistive touchscreen, VGA, LAN, three COM, four USB and fanless aluminium housing

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeCeleron
  • CPU Name2.00GHz
  • GPU/VGA TypeIntel HD Graphics

CPU Type Celeron

Struck-through versions exist but are not stocked here.

CPU Name 2.00GHz

Struck-through versions exist but are not stocked here.

GPU|Memory|SSD|HDD Intel HD Graphics|4GB DDR3|64GB|None

  • Intel HD Graphics 4400|4GB DDR3|64GB|None
  • Intel HD Graphics 4400|4GB DDR3|None
  • Intel HD Graphics 4400|8GB DDR3|256GB|1TB
  • Intel HD Graphics 4400|8GB DDR3|256GB|None
  • Intel HD Graphics 4400|8GB DDR3|512GB|None
  • Intel HD Graphics 4400|8GB DDR3|None
  • Intel HD Graphics|4GB DDR3|64GB|None
  • Intel HD Graphics|4GB DDR3|None
  • Intel HD Graphics|8GB DDR3|256GB|1TB
  • Intel HD Graphics|8GB DDR3|256GB|None
  • Intel HD Graphics|8GB DDR3|512GB|None
  • Intel HD Graphics|8GB DDR3|None
  • Intel Iris Graphics 540|4GB DDR3|64GB|None
  • Intel Iris Graphics 540|4GB DDR3|None
  • Intel Iris Graphics 540|8GB DDR3|256GB|1TB
  • Intel Iris Graphics 540|8GB DDR3|256GB|None
  • Intel Iris Graphics 540|8GB DDR3|512GB|None
  • Intel Iris Graphics 540|8GB DDR3|None

Struck-through versions exist but are not stocked here.

  • IP65 front protection shields against dust and water jets
  • Fanless aluminium chassis runs silently from 0 °C to 50 °C
  • Intel Celeron J1900 up to 2.42 GHz drives industrial workloads
  • 4 GB DDR3L and 64 GB mSATA SSD boot Windows 10 Pro instantly
  • VGA, LAN, three COM, four USB plus Mini PCIe slot for expansion

Compact industrial panel PC

The 12.1 inch all-in-one unit combines a fanless aluminium chassis with an IP65-rated front panel. An Intel Celeron J1900 processor, 4 GB DDR3L memory and a 64 GB mSATA SSD come pre-installed with Windows 10 Pro. The resistive touchscreen operates reliably across a 0 to 50 °C range, making the system suited for factory automation, kiosk and embedded control tasks.

Expandable I/O and storage options

A full-size Mini PCIe slot with a SIM holder allows wireless or 4G modules to be added later. One 2.5 inch SATA bay and the mSATA socket give flexibility for additional SSD or HDD capacity. The port selection includes VGA, Gigabit LAN, three USB 2.0, one USB 3.0, three COM ports and dual audio jacks, covering legacy and modern peripherals without extra adapters.

Fanless build with versatile mounting

The sealed aluminium housing dissipates heat silently, eliminating moving-part failure in dusty or vibration-prone environments. Embedded buckle kits, VESA 75 compatibility and a 301 x 229 mm cut-out dimension support panel, wall, desktop or cantilever installation. DC 12 V input with auto-recovery after power loss ensures continuous operation in unstable supply conditions.

Highlights

  • IP65 front protection shields against dust and water jets
  • Fanless aluminium chassis runs silently from 0 °C to 50 °C
  • Intel Celeron J1900 up to 2.42 GHz drives industrial workloads
  • 4 GB DDR3L and 64 GB mSATA SSD boot Windows 10 Pro instantly
  • VGA, LAN, three COM, four USB plus Mini PCIe slot for expansion

Specifications

ModelA2-PA-121TPC-CE5B(J19)-4G64G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeCeleron
CPU Name2.00GHz
GPU/VGA TypeIntel HD Graphics
Memory Capacity4GB DDR3
SSD64GB
HDDNo
Screen Size12.1"
TouchscreenYes

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How long does the 12.1" resistive touch screen last before it needs replacing?

The five-wire resistive touch screen is rated for 200 million touches and the LED backlight has a minimum life of 30,000 hours.

What limits continuous operation of the fanless Intel Celeron J1900 system?

The aluminium chassis must stay within 0 – 50 °C ambient when an SSD is fitted; above that the CPU will throttle to protect itself.

How much power does the 12V DC panel PC draw and does it get noisy when running 24/7?

The fanless design makes it completely silent; power comes from a 100 – 240 V AC adapter that supplies 12 V DC to the unit.
