15 inch gray aluminum all in one panel pc with capacitive touchscreen

partaker

partaker A27 15" AI edge system i5-3317U 4GB 128GB

SKU CH-TXDC-8ED2T

A 15-inch fanless industrial panel PC with an IP65-rated capacitive touchscreen, Intel Core i5-3317U processor, 4 GB DDR3 memory, 128 GB mSATA storage, dual Gigabit LAN, HDMI, two COM ports.

  • TypeAll-in-One PC
  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 3rd Gen
  • CPU NameIntel Core i5-3317U

A27 15" Capacitive I5 3317U 4GB RAM / 128GB SSD

  • 4GB RAM / 128GB SSD
  • 8GB RAM / 128GB SSD
  • 8GB RAM / 256GB SSD
  • 8GB RAM / 512GB SSD

Struck-through versions exist but are not stocked here.

  • Silent fanless aluminium chassis for dusty industrial sites
  • IP65 front panel resists water and dust ingress
  • Capacitive 15 inch touchscreen with 1024×768 resolution
  • Dual Gigabit LAN plus four USB and two COM ports
  • Wide 9–36 V DC input operates from –20 to +60 °C

Industrial 15-inch Panel PC

The Partaker A27 is a 15-inch all-in-one industrial computer built around an Intel Core i5-3317U processor, 4 GB of DDR3 memory and a 128 GB mSATA drive. Its capacitive touchscreen and IP65-rated front panel suit factory automation, logistics terminals and outdoor kiosks. The aluminium chassis is fanless and supports embedded mounting via a 355×279 mm cutout. Windows 10 Pro is pre-installed.

Sustained load on dual-core i5-3317U

The dual-core i5-3317U runs at up to 2.60 GHz without active cooling, so performance under continuous load is governed by passive heat dissipation through the aluminium shell. In long-running automation tasks the processor will throttle to stay within its thermal envelope rather than maintain peak frequency. The fanless design eliminates moving-part wear but limits the duration of full-speed compute bursts.

Thermals noise and power in normal use

Operating from -20 °C to +60 °C with an SSD installed, the system draws 12 V DC as standard and can accept a 9–36 V wide-range supply when ordered. With no fans the unit is silent; the 350 cd/m² display and two 8 W speakers are the main audible and thermal contributors. Dual Gigabit Ethernet, HDMI, dual COM ports and four USB ports are active without raising chassis temperature above ambient in typical monitoring workloads.

Highlights

  • Silent fanless aluminium chassis for dusty industrial sites
  • IP65 front panel resists water and dust ingress
  • Capacitive 15 inch touchscreen with 1024×768 resolution
  • Dual Gigabit LAN plus four USB and two COM ports
  • Wide 9–36 V DC input operates from –20 to +60 °C

Specifications

TypeAll-in-One PC
Form FactorAll-in-One
ColorGray
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 3rd Gen
CPU NameIntel Core i5-3317U
Screen Size15"
Screen TypeMulti-Touch Screen

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the fanless aluminium chassis stay quiet and cool when the i5-3317U runs at 2.60 GHz all day?

The fanless aluminium alloy chassis is designed for silent, maintenance-free operation and the system is rated to operate continuously from -20 to +60 °C with solid-state storage.

What mounting cutout and voltage supply do I need before installing the A27 panel PC?

The embedded mount requires a 355×279 mm panel cutout and the standard input is 12 V DC, with an optional 9~36 V DC wide-range option available.

Can I keep using my existing RS-232/485 devices and VGA-era monitors with the dual-display outputs?

The A27 provides two configurable COM ports (RS232/485, expandable to six) and synchronous/asynchronous dual display via HDMI and the internal LVDS connection.
