13.3 inch all-in-one panel PC with resistive touchscreen and fanless aluminium chassis

partaker

partaker A3 13.3" all-in-one PC i7-1165G7 16GB DDR4 512GB SSD 1TB HDD

SKU CH-F1WM-HJD7Q

13.3-inch fanless all-in-one with IP65 front panel, i7-1165G7, 16GB DDR4, 512GB SSD and 1TB HDD for industrial use

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 11th Gen
  • GPU/VGA TypeIntel Iris Xe Graphics
  • Memory Capacity16GB DDR4
  • SSD512GB

Memory Capacity 16GB DDR4

SSD 512GB

HDD 1TB

Struck-through versions exist but are not stocked here.

  • IP65 front panel resists dust and water in harsh environments
  • Intel Core i7-1165G7 handles continuous 24/7 industrial workloads
  • Fanless aluminium chassis runs silently without moving parts
  • Dual LAN plus VGA HDMI USB 3.0 2.0 and COM ports connect legacy and modern gear
  • 16 GB DDR4 with 512 GB SSD and 1 TB HDD stores OS apps and large data sets

Industrial panel PC with i7-1165G7

The Partaker A3 integrates a 13.3 inch TFT LED display with a resistive touchscreen into a single fanless chassis. An Intel Core i7 11th Gen processor and 16GB of DDR4 memory provide compute performance for continuous industrial workloads. Dual storage combines a 512GB M.2 SSD with a 1TB 2.5 inch SATA drive for operating system speed and data capacity. The front panel carries an IP65 rating for protection against dust and water jets.

Fanless cooling and power envelope

An aluminum alloy passive cooling system eliminates fans, delivering silent operation suited to 24/7 deployment. The unit runs on a 12V DC input supplied by an external 100-240V AC adapter, simplifying power planning in control cabinets. Operating temperature ranges reach 0 to 50°C when the SSD is the primary drive and 0 to 40°C with the mechanical hard drive active. Humidity tolerance spans 10 to 95 percent at 40°C without condensation.

Mounting flexibility and legacy I/O

The chassis measures 334.2 by 229.85 by 52.5 mm and weighs 3.4 kg, fitting a 326 by 232 mm cut-out for embedded or wall-mounted installation. Video output is provided through HDMI and VGA ports for mixed-generation display setups. Two USB 3.0 ports, two USB 2.0 ports, dual LAN, two COM ports and audio I/O support a wide range of industrial peripherals. Internal M.2 Key E and Key B slots allow optional WIFI6 or 5G expansion with a SIM slot.

Highlights

  • IP65 front panel resists dust and water in harsh environments
  • Intel Core i7-1165G7 handles continuous 24/7 industrial workloads
  • Fanless aluminium chassis runs silently without moving parts
  • Dual LAN plus VGA HDMI USB 3.0 2.0 and COM ports connect legacy and modern gear
  • 16 GB DDR4 with 512 GB SSD and 1 TB HDD stores OS apps and large data sets

Specifications

ModelA3-PA-133TPC-CE5A(I7B)-16G512G1TB
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 11th Gen
GPU/VGA TypeIntel Iris Xe Graphics
Memory Capacity16GB DDR4
SSD512GB
HDD1TB
Screen Size13.3"
TouchscreenYes

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I mount the A3 in a 326 x 232 mm cut-out and what is the step people forget?

Cut the opening to 326 x 232 mm, insert the unit from the front, and secure the supplied mounting brackets; the step often missed is tightening all four brackets evenly so the IP65 front seal seats uniformly.

Which components will need replacement first and what are their rated lifetimes?

The resistive touch layer is rated for 35 million touches and the LED backlight for a minimum of 20,000 hours; both are the primary wear items under continuous industrial use.

What thermal limit appears first during sustained 24/7 operation?

With the fanless aluminium chassis the internal temperature ceiling is reached at 50 °C when an SSD is installed, or 40 °C when the 2.5" HDD is active, triggering throttling before any other limit.
