15.6 inch IP65 all-in-one panel PC with aluminium fanless chassis and projected capacitive touchscreen

partaker

Partaker A6 15.6" IP65 all-in-one PC i7-6500U 8GB DDR3 256GB SSD 1TB HDD

SKU CH-H6ZQ-1DZXB

15.6 inch IP65 touchscreen all-in-one with i7-6500U, 8GB DDR3, 256GB SSD and 1TB HDD for industrial use

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 6th Gen
  • GPU/VGA TypeIntel HD Graphics 520
  • Memory Capacity8GB DDR3
  • SSD256GB

Memory Capacity 8GB DDR3

  • IP65 front panel resists dust and water jets in harsh environments
  • 10-point projected capacitive touchscreen enables precise multi-touch control
  • Fanless aluminium alloy cooling runs silently with no moving parts
  • Intel Core i7-6500U up to 3.10 GHz handles heavy 24/7 workloads
  • Dual storage with 256 GB SSD and 1 TB HDD provides fast boot and large capacity

Industrial touch panel PC

The Partaker A6 is a 15.6 inch all-in-one computer with an IP65 rated front panel and 10 point projected capacitive touchscreen. It runs on an Intel Core i7 6500U processor with Intel HD Graphics 520, 8GB DDR3L memory, a 256GB SSD and a 1TB HDD. Windows 11 Pro comes pre installed for immediate deployment in industrial settings.

Fanless upgrade for legacy systems

This unit replaces older panel PCs that rely on active cooling and lower ingress protection. The aluminium alloy fanless design enables silent 7x24 operation in dusty or wet environments where traditional units fail. The jump is worthwhile when a sealed front face, passive thermal management and modern OS support are required for continuous automation or HMI tasks.

Dual drive capacity with expansion headroom

The 256GB mSATA SSD handles the operating system and frequent read write cycles while the 1TB 2.5 inch SATA drive stores large datasets and logs. Two SODIMM slots support up to 16GB DDR3L 1600 memory for heavier multitasking. An M.2 2280 slot and Mini PCIe slot with SIM holder allow additional NVMe or SATA storage and 4G or WiFi connectivity. Operating temperature reaches 50°C with SSD only and 40°C when the mechanical drive is active.

Highlights

  • IP65 front panel resists dust and water jets in harsh environments
  • 10-point projected capacitive touchscreen enables precise multi-touch control
  • Fanless aluminium alloy cooling runs silently with no moving parts
  • Intel Core i7-6500U up to 3.10 GHz handles heavy 24/7 workloads
  • Dual storage with 256 GB SSD and 1 TB HDD provides fast boot and large capacity

Specifications

ModelA6-PA-156TPC-CE6A(I76))-8G256G1TB
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 6th Gen
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity8GB DDR3
SSD256GB
HDD1TB
Screen Size15.6"
TouchscreenYes

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What size opening does the 15.6" A6 need for panel-mount installation?

The front panel fits a cut-out of 386.5 x 236 mm, and the unit measures 392.6 x 241.7 x 54.5 mm overall. Mounting brackets are included.

How is the 12 V DC power connected, and what mistake should be avoided?

Plug the external 100-240 V AC adapter into the 12 V DC jack on the I/O panel; do not apply raw mains voltage directly to the DC input.

Which storage drives can be added or swapped later in the A6?

One mSATA SSD, one M.2 2280 NVMe or SATA SSD, and one 2.5" SATA SSD or HDD are supported; the board also takes two DDR3L-1600 SODIMM modules up to 16 GB total.
