15.6 inch IP65 resistive touch panel PC aluminium fanless chassis

partaker

partaker A7 15.6" i7-6500U 8GB 128GB SSD AI edge system

SKU CH-JBNF-X42N4

A 15.6 inch IP65 resistive touchscreen panel PC with Intel i7-6500U, 8GB DDR3, 128GB SSD, fanless cooling and Windows 11 Pro for 7x24 industrial use

  • Form FactorAll-in-One
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i7 6th Gen
  • GPU/VGA TypeIntel HD Graphics 520
  • Memory Capacity8GB DDR3
  • HDDNo
  • IP65 front panel protects against dust and water ingress in harsh environments
  • Intel Core i7-6500U processor delivers reliable performance for continuous 24/7 operation
  • Fanless aluminium alloy cooling ensures silent running and high energy efficiency
  • 6 inch TFT LED display with 1920 x 1080 resolution provides clear visuals
  • Versatile I/O including HDMI, VGA, dual LAN, USB 3.0 and COM ports supports diverse industrial connections

15.6" IP65 industrial panel PC for continuous

The Partaker A7 is a fanless all-in-one system built around an Intel Core i7-6500U processor and 8 GB of DDR3L memory. Its 15.6 inch TFT LED display carries an IP65 front-panel rating and a high-temperature five-wire resistive touchscreen rated for 35 million touches. The unit ships with Windows 11 Pro 64-bit installed and operates from 0 to 50 °C with the fitted 128 GB SSD.

8 GB DDR3L and 128 GB SSD with room to grow

Two SODIMM slots accept DDR3L-1600 modules up to a combined 16 GB, giving headroom for heavier workloads. Storage can be expanded through an mSATA slot, an M.2 2280 socket that supports NVME or SATA, and a 2.5 inch SATA bay for additional SSDs or hard drives. The current 128 GB SSD handles the OS and core applications; larger data sets will require populating the extra bays.

Embedded mounting kit

The box includes the panel PC, a 12 V power supply, a power cable and embedded mounting buckles for flush-panel installation. Connectivity covers HDMI, VGA, two USB 3.0, two USB 2.0, dual LAN, audio in/out and two COM ports, plus a Mini PCIe slot with a SIM holder for wireless expansion. A hardware watchdog timer with 255 levels supports automatic power-on after failure for unattended 24/7 operation.

Highlights

  • IP65 front panel protects against dust and water ingress in harsh environments
  • Intel Core i7-6500U processor delivers reliable performance for continuous 24/7 operation
  • Fanless aluminium alloy cooling ensures silent running and high energy efficiency
  • 6 inch TFT LED display with 1920 x 1080 resolution provides clear visuals
  • Versatile I/O including HDMI, VGA, dual LAN, USB 3.0 and COM ports supports diverse industrial connections

Specifications

ModelA7-PA-156TPC-CE5A(I76))-8G128G
Form FactorAll-in-One
Operating SystemWindows 11 Pro
CPU TypeIntel Core i7 6th Gen
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity8GB DDR3
HDDNo
Screen Size15.6"
TouchscreenYes

Questions about this item

Will the 12 V DC power input work with my existing 12 V industrial PSU?

Yes, the unit accepts 12 V DC from the included 100–240 V AC adapter, so any 12 V supply that meets the same voltage and current rating can replace it.

How can I verify the 5-wire resistive touchscreen is calibrated correctly after installation?

Open the Windows 11 Pro tablet settings, run the built-in calibration tool and confirm touch points register accurately across the 1920 x 1080 panel.

Does the box contain the mSATA and M.2 drives or only the 128 GB SSD already fitted?

The packing list includes the Partaker A7 panel PC, the 12 V power supply and the power cord; the 128 GB SSD is pre-installed and additional mSATA or M.2 drives must be purchased separately.
