Thin green circuit board M.2 2280 SSD with black controller and silver label

Patriot Memory

Patriot Memory P320P512GM28 512GB internal SSD

SKU CH-NFZF-DV0C8 MPN P320P512GM28

M.2 2280 NVMe drive with 512 GB capacity, PCIe 3.0 x4 speeds up to 3000 MB/s read and 2200 MB/s write, 240 TBW endurance, DRAM-less HMB cache, 0.37 W idle and 2.07 W active power

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity512GB
  • InterfacePCI-Express 3.0 x4
  • ProtocolNVMe 1.3
  • Up to 3000 MBps sequential read for fast boot times
  • Up to 2200 MBps sequential write for quicker file transfers
  • 240TB endurance rating supports long-term reliability
  • PCIe 3.0 x4 interface with NVMe 1.3 protocol enables high throughput
  • Low 0.37W idle power draw helps extend laptop battery life

Capacity and form factor

The Patriot P320 is a 512GB internal solid state drive built to the M.2 2280 form factor. It connects through a PCI-Express 3.0 x4 interface and runs on the NVMe 1.3 protocol. The drive is designed for consumer desktops and laptops that need faster storage than a traditional hard disk.

Upgrade path and value

It replaces a mechanical hard drive or a PCIe 3.0 x2 SSD with sequential reads up to 3000 MBps and writes up to 2200 MBps. The 240TB endurance rating supports heavy daily workloads. The jump is worthwhile when boot times, application loading and file transfers feel sluggish on older storage.

Compatibility checklist

Verify that your motherboard or laptop has an M.2 slot keyed for PCIe 3.0 x4 NVMe operation. The module measures 22.00mm wide and 3.80mm high without a heatsink. Idle power draw is 0.37W and active draw is 2.07W. Operating temperature range is 0°C to 70°C.

Highlights

  • Up to 3000 MBps sequential read for fast boot times
  • Up to 2200 MBps sequential write for quicker file transfers
  • 240TB endurance rating supports long-term reliability
  • PCIe 3.0 x4 interface with NVMe 1.3 protocol enables high throughput
  • Low 0.37W idle power draw helps extend laptop battery life

Specifications

BrandPatriot
SeriesP320
ModelP320P512GM28
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity512GB
InterfacePCI-Express 3.0 x4
ProtocolNVMe 1.3
CacheNo DRAM (HMB)
Max Sequential ReadUp to 3000 MBps
Max Sequential WriteUp to 2200 MBps
Terabytes Written (TBW)240TB
HeatSinkwithout HeatSink
FeaturesThe P320 is Patriot’s next generation of high-tier PCIe gen 3x4 NVMe SSD to hit the market, offering much higher transfer speeds and IOPs than standard PCIe 3x2 solutions. The compact m.2 form factor is designed for easy installation and will fit into any PC or laptop, while its low power consumption helps extend laptop battery life. The P320 is guaranteed to improve start-up, loading, and transfer times over traditional hard disk drives.
The P320’s advanced firmware offers thermal throttling technology and end-to-end data path protection to ensure data integrity throughout the life
Power Consumption (Idle)0.37W
Power Consumption (Active)2.07W
Operating Temperature0°C ~ +70°C
Height3.80mm
Width22.00mm
Depth80.00mm
Weight9.00g
Shipping weight0.05 kg
Package size133 × 102 × 0 mm
