Green circuit board M.2 2280 SSD with black label, no heatsink

Patriot Memory

Patriot Memory P400LP2KGM28H 2TB internal SSD

SKU CH-9TGA-SE5FP MPN P400LP2KGM28H

A 2 TB M.2 2280 NVMe SSD with PCIe 4.0 x4 interface, up to 3500 MB/s read and 2700 MB/s write, 2000 TBW endurance and graphene heatshield

  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • InterfacePCI-Express 4.0 x4
  • ProtocolNVMe 2.0
  • CacheNo DRAM (HMB)

Capacity P400 Lite Gen 4

speed 2TB 3,500MB/s

  • Sequential reads up to 3500 MB/s for fast boot times
  • Sequential writes up to 2700 MB/s for quick file transfers
  • 2TB capacity stores large game libraries and media
  • PCIe 4.0 x4 interface with NVMe 2.0 protocol enables high throughput
  • End-to-End Datapath Protection helps maintain data integrity

2TB PCIe 4.0 NVMe drive for consumers

This M.2 2280 SSD uses a PCI-Express 4.0 x4 interface and the NVMe 2.0 protocol. It is built for consumer workloads such as gaming, content creation and everyday computing. The drive has no onboard DRAM and relies on Host Memory Buffer support.

PCIe 4.0 x4 bandwidth caps peak throughput

The interface limits maximum sequential reads to 3500 MBps and writes to 2700 MBps. Operating temperature is rated from 0°C to 70°C. Endurance is specified at 2000 TBW, which defines the practical write lifetime for this capacity.

DRAM-less design with Host Memory Buffer

The controller uses system memory through HMB instead of a dedicated cache die. This reduces component cost and power draw while still delivering PCIe 4.0 speeds. Buyers should confirm their platform enables HMB for best performance.

Highlights

  • Sequential reads up to 3500 MB/s for fast boot times
  • Sequential writes up to 2700 MB/s for quick file transfers
  • 2TB capacity stores large game libraries and media
  • PCIe 4.0 x4 interface with NVMe 2.0 protocol enables high throughput
  • End-to-End Datapath Protection helps maintain data integrity

Specifications

BrandPatriot
SeriesViper P400 Lite
ModelP400LP2KGM28H
Part NumberP400LP2KGM28H
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
InterfacePCI-Express 4.0 x4
ProtocolNVMe 2.0
CacheNo DRAM (HMB)
Max Sequential ReadUp to 3500 MBps
Max Sequential WriteUp to 2700 MBps
Terabytes Written (TBW)2000TB
HeatSinkwithout HeatSink
Features• Built with the latest PCIe Gen4 x4 controller
• Compliant with NVMe 2.0
• Support Host Memory Buffer
• Compatible with PS5
• Support Toggle 5 and ONFi 5 mode Flash, up-to double data rate at 2400MT/s
• High efficiency slim Graphene heatshield
• Embedded thermal sensor for thermal throttling
• Operating Temperature: 0 ~ 70°C
• SmartECC technology
• O/S Supported: Windows® 7*/8.0*/8.1/10/11
Operating Temperature0°C ~ +70°C
Shipping weight0.02 kg
Package size133 × 102 × 6 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this M.2 2280 drive fit in my laptop that has a single M.2 slot?

Yes, the drive uses the standard M.2 2280 form factor, so it will fit any laptop or desktop slot built to that size.

Does the drive need a separate heatsink for a PlayStation 5 installation?

No, the drive includes an integrated graphene heatshield and is listed as compatible with PS5 without requiring an additional heatsink.

My motherboard only supports PCIe 3.0 — will the drive still work at full capacity?

The drive will work but will be limited to PCIe 3.0 speeds; it will not reach the stated 3500 MB/s read or 2700 MB/s write figures on that platform.
