White 90 degree dual rotary elbow fitting with male and female G 1/4 threads

PrimoChill

PrimoChill G1/4 90° Dual Rotary Elbow Fitting Sky White diy cooling

SKU CH-W86P-ERFKY

A G 1/4 male-to-female 90-degree dual rotary elbow fitting in Sky White for redirecting tubing runs in custom liquid-cooling loops

  • TypeCPU Block

Option Sky White

Show 10 more configurations

Struck-through versions exist but are not stocked here.

  • 90° dual-rotary design redirects tubing at unconventional angles
  • Male-to-female G 1/4 threads connect directly to standard water-cooling components
  • Coated brass construction with Sky White SX finish resists corrosion and matches loop aesthetics
  • Installed O-ring on male side provides immediate seal without extra parts
  • Rotary joints allow precise angular alignment after installation

G1/4 90° dual rotary elbow for custom loops

The PrimoChill Sky White fitting redirects tubing runs at a 90 degree angle using male and female G 1/4 threads. Its dual rotary joints let you aim the connection in multiple directions without stressing the loop. Coated brass construction provides a durable SX colour finish. One installed O-ring on the male side seals the thread.

Behaviour under sustained loop pressure

The rotary joints stay sealed during normal operation but can dislodge if the fitting is moved repeatedly after installation. Manufacturer guidance advises removing the fitting, pressing the joints back in and rotating them to reseat the seals before pressure testing. Using pressure valves with rotary fittings is strongly recommended to reduce the risk of leaks over time.

Male and female G 1/4 thread compatibility

This elbow only fits components and tubing terminations that use G 1/4 threads. Builders using other thread standards or push-fit connectors will need different adapters. The single male and female port layout also means it cannot join two male or two female ends directly.

Highlights

  • 90° dual-rotary design redirects tubing at unconventional angles
  • Male-to-female G 1/4 threads connect directly to standard water-cooling components
  • Coated brass construction with Sky White SX finish resists corrosion and matches loop aesthetics
  • Installed O-ring on male side provides immediate seal without extra parts
  • Rotary joints allow precise angular alignment after installation

Specifications

TypeCPU Block

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the 90-degree dual rotary elbow generate extra heat or noise when the loop runs continuously?

No, the fitting is a passive brass component with no moving parts that produce heat or sound during operation.

What thread standard must my existing blocks, radiators or reservoirs already have for this fitting to connect?

Every component in the loop must use G 1/4-inch threads, which is the universal standard for custom water-cooling hardware.

Will the Sky White coated brass finish match older nickel-plated or chrome fittings I plan to keep?

The Candy SX coating is knurled and appears darker than smooth finishes, so it may not perfectly match legacy nickel or chrome parts.
