Compact three-bay desktop NAS in dark finish with front drive bays and top ventilation grille

Qnap

Qnap TS-364-8G-US 3-Bay Desktop NAS 8GB

SKU CH-WEXN-M303C MPN TS-364-8G-US

A three-bay desktop NAS with an Intel Celeron N5095 processor, 8 GB memory, 2.5GbE networking, HDMI 1.4 output and USB 3.2 ports, supporting RAID 5 and up to 66 TB raw capacity

  • TypeDesktop NAS
  • Ports1 x 2.5GbE / 1 x HDMI 1.4a / 1 x USB 3.2 Gen 1 / 2 x USB 3.2
  • Port RJ-451 x 2.5GbE
  • Port USB1 x USB 3.2 Gen 1 Port/2 x Type-A USB 3.2 Gen 2 (10Gbps) Por
  • HDD Interface3 x SATA (3 x Bay)
  • Form Factor3-Bay
  • 3-bay design supports RAID 5 with three drives for capacity and single-disk fault tolerance
  • 5GbE port delivers up to 2.5 times faster transfers over existing CAT5e cabling
  • Intel Celeron N5095 four-core processor bursts to 2.9 GHz for VMs and containers
  • Dual M.2 PCIe Gen 3 slots add cache acceleration or SSD storage pools
  • HDMI 1.4b outputs 4K at 4096 x 2160 resolution and 30 Hz for media playback

Three-bay desktop NAS with 2.5GbE

The Qnap TS-364-8G-US is a three-bay desktop network-attached storage device powered by an Intel Celeron N5095 four-core processor bursting to 2.9 GHz. It ships with 8 GB of installed memory that cannot be expanded further. The unit targets home users and small offices wanting a personal cloud for backup and media streaming without populating drive bays at purchase.

Dual M.2 slots and 4K HDMI output

Two M.2 PCIe Gen 3 slots accept SATA SSDs for cache acceleration or dedicated storage pools, while a single HDMI 1.4b port delivers 4K hardware decoding and real-time transcoding at up to 4096 x 2160 and 30 Hz. One 2.5GbE RJ-45 port, one USB 3.2 Gen 1 port and two USB 3.2 Gen 2 ports at 10 Gbps complete the I/O selection for external backup or peripheral expansion.

66 TB raw capacity with RAID 5 headroom

Three 3.5-inch SATA bays support up to 66 TB of raw storage, letting a three-disk RAID 5 array protect against a single drive loss while keeping two thirds of total capacity usable. The 65 W adapter draws 18.9 W typical, operating between 0 and 40 °C. Builders needing more than three internal drives or 10 GbE connectivity will require a larger chassis.

Highlights

  • 3-bay design supports RAID 5 with three drives for capacity and single-disk fault tolerance
  • 5GbE port delivers up to 2.5 times faster transfers over existing CAT5e cabling
  • Intel Celeron N5095 four-core processor bursts to 2.9 GHz for VMs and containers
  • Dual M.2 PCIe Gen 3 slots add cache acceleration or SSD storage pools
  • HDMI 1.4b outputs 4K at 4096 x 2160 resolution and 30 Hz for media playback

Specifications

BrandQNAP
Series3-Bay
ModelTS-364
Part NumberTS-364-8G-US
TypeDesktop NAS
Ports1 x 2.5GbE / 1 x HDMI 1.4a / 1 x USB 3.2 Gen 1 / 2 x USB 3.2 Gen 2
Port RJ-451 x 2.5GbE
Port USB1 x USB 3.2 Gen 1 Port/2 x Type-A USB 3.2 Gen 2 (10Gbps) Port/1 x HDMI 1.4b(up to 4096 x 2160 @ 30Hz)
HDD Interface3 x SATA (3 x Bay)
Form Factor3-Bay
ProcessorIntel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz
Installed Memory8GB
Max Memory Capacity8GB
Included HDD CapacityDiskless System
Max Capacity66TB
Drive Compatibility3.5" SATA HDD
2.5" SATA SSD
Power65W adapter, 100 - 240V
Power Consumption18.9W
TemperatureOperating Temperature: 0 - 40 °C (32°F - 104°F)
Storage Temperature: -20 - 70°C (-4°F - 158°F)
Humidity5-95% RH non-condensing, wet bulb: 27°C (80.6°F)
UsageBackup & stream media through personal cloud
Dimensions10.24'x5.91'x5.59'
Weight3.62lb
Package ContentsEthernet Cable x 1
Power Cord x 1
AC Adapter: PWR-ADAPTER-65W-A01
Quick Installation Guide (QIG)
Shipping weight2.88 kg
Package size325 × 267 × 216 mm

Questions about this item

Will the 8 GB of soldered memory on the TS-364 ever need to be upgraded or replaced?

The unit ships with 8 GB installed and the maximum supported capacity is also 8 GB, so no memory upgrade is possible and no replacement is expected under normal use.

What throughput ceiling will I hit first when the 2.5GbE port runs flat-out for hours?

The single 2.5GbE RJ-45 link caps sustained network traffic at 2.5 Gbps, which becomes the bottleneck before the Intel Celeron N5095 processor reaches its 2.9 GHz burst limit.

How much heat and fan noise should I expect from the 65 W adapter when the NAS runs all day?

Typical draw is 18.9 W, well below the 65 W adapter rating, and the chassis is rated for 0–40 °C operation, so heat output and fan activity stay modest during continuous use.
