M.2 2280 internal SSD with integrated heatsink, black circuit board, silver metal cover

Rahonix

Rahonix XP3000-512 2280 with HeatSink internal SSD

SKU CH-SFR2-WYE1C

512 GB M.2 2280 NVMe SSD with PCIe 3.0 x4 interface, up to 3400 MB/s read and 2500 MB/s write, 500 TBW endurance and an integrated heatsink

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity512GB
  • Memory Components3D NAND
  • InterfacePCI-Express 3.0 x4
  • Sequential read up to 3500 MBps speeds up game and app loading
  • Sequential write up to 2500 MBps handles large files and multitasking smoothly
  • Integrated heatsink dissipates heat to maintain performance during heavy workloads
  • 500 TBW endurance rating supports long-term daily use
  • Low idle power draw of .6 W extends laptop battery life

XP3000 512 GB PCIe 3.0 x4 NVMe drive

The XP3000-512 2280 is a consumer M.2 2280 solid state drive with 512 GB of 3D NAND storage. It connects through a PCI-Express 3.0 x4 lane running the NVMe 1.3 protocol. The drive targets desktop and laptop users who want faster boot, application load and file transfer speeds than a SATA SSD can provide. An integrated heatsink is included to help manage thermals in compact chassis.

Sustained workload behaviour and endurance

Sequential read reaches up to 3400 MBps while sequential write tops out at 2500 MBps. The drive is rated for 500 TBW and an MTBF of 1000000 hours, indicating it can maintain performance across heavy daily write cycles. Active power draw is 4 W and idle draw is .6 W, so thermal output stays modest during extended sessions. Operating temperature range is 0 °C to 70 °C.

Build, connectors and daily implications

The single-sided M.2 2280 board measures 80.0 mm by 22.0 mm by 2.1 mm and uses a graphene thermal label beneath the heatsink for heat spread. It mounts with the supplied screw into any standard M.2 slot keyed for PCIe 3.0 x4. No moving parts means silent, vibration-resistant operation. The 3.3 V supply and low idle power suit both desktop and thin-and-light laptop designs.

Highlights

  • Sequential read up to 3500 MBps speeds up game and app loading
  • Sequential write up to 2500 MBps handles large files and multitasking smoothly
  • Integrated heatsink dissipates heat to maintain performance during heavy workloads
  • 500 TBW endurance rating supports long-term daily use
  • Low idle power draw of .6 W extends laptop battery life

Specifications

BrandRahonix
SeriesXP3000
ModelXP3000-512 2280
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity512GB
Memory Components3D NAND
InterfacePCI-Express 3.0 x4
ProtocolNVMe 1.3
Max Sequential ReadUp to 3400 MBps
Max Sequential WriteUp to 2500 MBps
Terabytes Written (TBW)500TB
MTBF1,000,000 hours
HeatSinkwith HeatSink
Power Consumption (Idle)0.6W
Power Consumption (Active)4W
Operating Temperature0°C ~ +70°C
Storage Temperature-20°C ~ +75°C
Operating Humidity5% to 95% RH
Height22mm
Width80mm
Depth2.1mm
Weight15g
Package Content1*SSD, 1*screw, 1*box package

Questions about this item

How much power does the XP3000-512 draw while running all day?

The drive idles at .6W and reaches 4W under load, with an operating range of 0°C to 70°C.

What slot and screw does the XP3000-512 need to install?

It fits an M.2 2280 PCIe 3.0 x4 slot and includes one mounting screw in the box.

Will the XP3000-512 work alongside a SATA SSD I already own?

Yes — it uses the NVMe 1.3 protocol on PCIe 3.0 x4, so it runs independently of any SATA drive.
