White 10.1 inch all-in-one touchscreen tablet with black display bezel

RAYPODO

RAYPODO 10.1" RK3566 White 2GB+16GB all-in-one PC

SKU CH-3PXJ-A12TB

A 10.1-inch Android 11 all-in-one with RK3566 quad-core, 2 GB LPDDR4X, 16 GB eMMC, 10-point touch, PoE RJ45, HDMI out and no battery for kiosk mounting

  • Screen Size10.1"
  • Screen Resolution1280*800
  • TouchscreenYes
  • Screen Type10-Point capacitive touch, LCD IPS panel
  • Display Feature10.1" 1280*800 IPS, 10-Point capacitive touch, Normally blac
  • CPU NameRK3566

memory 2GB+16GB

color White

  • Quad-core RK3566 Cortex-A55 handles kiosk workloads smoothly
  • 10-point capacitive IPS touch at 1280×800 gives accurate input
  • PoE over RJ45 removes separate power cabling
  • 2 GB LPDDR4X plus 16 GB eMMC stores local content
  • Wi-Fi 802.11b/g/n and Bluetooth 5.0 connect peripherals

Compact Commercial All-in-One

The RAYPODO 10.1-inch all-in-one PC runs Android 11 on an RK3566 quad-core Cortex-A55 processor with 2GB LPDDR4X memory and 16GB eMMC storage. It is built for fixed indoor deployments such as digital kiosks, hotel lobby displays, and office reception signage where a battery-free, wall-mounted form factor is required.

Passive Thermals and POE Power

The fanless design produces no audible noise and draws power solely through the RJ45 port using Power over Ethernet, eliminating a separate power adapter. The Mali-G52-2EE GPU drives the 1280 by 800 IPS panel at 250 cd/m² while the 802.11b/g/n Wi-Fi and Bluetooth 5.0 modules operate within the same low-power envelope.

Integration-Focused Connectivity

A single Ethernet cable supplies both 100M/1000M data and power, reducing cable count for tidy wall mounting. The 10-point capacitive touchscreen, HDMI output, and microSD expansion slot support interactive content and external displays, while the absence of a battery removes maintenance cycles for permanent installations.

Highlights

  • Quad-core RK3566 Cortex-A55 handles kiosk workloads smoothly
  • 10-point capacitive IPS touch at 1280×800 gives accurate input
  • PoE over RJ45 removes separate power cabling
  • 2 GB LPDDR4X plus 16 GB eMMC stores local content
  • Wi-Fi 802.11b/g/n and Bluetooth 5.0 connect peripherals

Specifications

Screen Size10.1"
Screen Resolution1280*800
TouchscreenYes
Screen Type10-Point capacitive touch, LCD IPS panel
Display Feature10.1" 1280*800 IPS, 10-Point capacitive touch, Normally black, 250cd/m2, 16:9
CPU NameRK3566
CPU TypeQuad-Core ARM Cortex-A55
CPU Main FeaturesRK3566 Quad-Core ARM Cortex-A55
Memory Capacity2GB
Form FactorAll-in-One
Memory Spec2GB LPDDR4X/LPDDR4
SSD16GB EMMC
HDD16GB EMMC
Storage Spec2GB+16GB
GPU/VGA TypeMali-G52-2EE
Graphics CardMali-G52-2EE
Graphics InterfaceMali-G52-2EE
WLAN802.11b/g/n
ModemWiFi 802.11b/g/n, Bluetooth 5.0
LAN Speed100M/1000M
BluetoothBluetooth 5.0
BrandRaypodo
TypeAll in one PC, POE Tablet
UsageDigital Kiosks, Indoor commercial use
ColorWhite
ProcessorRK3566
Processor Main FeaturesQuad-Core ARM Cortex-A55
Memory2GB LPDDR4X/LPDDR4
Storage16GB EMMC
GraphicsMali-G52-2EE
Ethernet100M/1000M Ethernet, RJ45 with POE
Wireless Card802.11b/g/n WiFi, Bluetooth 5.0
Monitor10.1" LCD IPS panel
Speaker2*8Ω 2W
Software IncludedAndroid 11
Special FeaturesPOE, Touchscreen, RJ45, All in one PC
Cosmetic ConditionWhite
ChipsetRK3566
Audio Channels2 channels
Audio FeaturesSupports MP3/WMA/AAC etc. audio format
Front USB2
Card ReaderTF card (Max Support 128GB)
Video PortsHD-MI output
Rear USB2 x USB ports
RJ45RJ45 with POE
PC Card SlotTF card (Max Support 128GB)
WebcamFront Camera 2.0 M/P
Speaker Configuration2*8Ω 2W
Consumer AlertNot include a battery, Not Consumer Tablet

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install this all-in-one PC using the RJ45 port for PoE power?

Connect an Ethernet cable from a PoE-capable switch or injector to the RJ45 port; the 100M/1000M LAN link supplies both data and power so no separate adapter is needed.

What storage expansion does the 16GB eMMC support for future needs?

A TF card slot is available to add removable storage beyond the fixed 16GB eMMC.

What thermal limit appears first when the RK3566 runs sustained loads?

The passively cooled quad-core Cortex-A55 will throttle clock speeds once its internal temperature threshold is reached.
