Reolink 16-channel 4K PoE kit with 16 bullet cameras and NVR

Reolink

Reolink RLK16-820D16-A 4K 16CH PoE surveillance security system

SKU CH-D1PB-KJA6W

A 16-channel 4K PoE kit with 16 IP cameras, person/vehicle detection, a pre-installed 4TB HDD and 18-metre cables for continuous recording

  • TypeNVR Kit
  • Camera TypeIP Camera
  • Camera inputs16 Channel
  • Resolution Recording8 Megapixels
  • Recording Frame Rate1 ~ 30 FPS
  • ONVIFYes

Camera inputs 16 Channel

Storage Capacity 4TB HDD

  • 4K Ultra HD captures 3840 x 2160 detail for precise identification
  • Person and vehicle detection reduces false alerts from animals or shadows
  • 16-channel PoE NVR with pre-installed 4 TB HDD enables 24/7 recording
  • IP66 weatherproof cameras operate reliably indoors and outdoors
  • Two SATA ports allow storage expansion up to 6 TB

16-Channel 4K PoE Surveillance Kit

This Reolink system bundles a 16-channel NVR with sixteen 8-megapixel IP cameras and eighteen-metre Cat5 cables. Each camera records at 3840 by 2160 resolution and captures audio through a built-in microphone. Power, video and sound travel over a single PoE connection for straightforward installation.

Suits Large Properties Needing Wired Coverage

Homeowners or businesses that want continuous 24/7 recording across up to sixteen fixed viewpoints will find the pre-installed 4TB drive and person/vehicle detection useful. Buyers who require wireless flexibility or battery-operated cameras should look elsewhere, as the kit relies on cabled PoE links and the NVR does not support third-party Wi-Fi models.

4TB Storage With Expansion Headroom

The included 4TB drive handles round-the-clock footage from all sixteen channels at up to 30 frames per second. Two internal SATA ports accept one additional drive up to 6TB, doubling capacity when retention needs grow. Without the extra drive the system will overwrite the oldest files once the 4TB limit is reached.

Highlights

  • 4K Ultra HD captures 3840 x 2160 detail for precise identification
  • Person and vehicle detection reduces false alerts from animals or shadows
  • 16-channel PoE NVR with pre-installed 4 TB HDD enables 24/7 recording
  • IP66 weatherproof cameras operate reliably indoors and outdoors
  • Two SATA ports allow storage expansion up to 6 TB

Specifications

BrandReolink
ModelRLK16-820D16-A
Part NumberRLK16-820D16-A
TypeNVR Kit
Camera TypeIP Camera
Camera inputs16 Channel
Resolution Recording8 Megapixels
Recording Frame Rate1 ~ 30 FPS
ONVIFYes
Max Resolution4K
Built-In HDDYes
Storage Capacity4TB HDD
Network ConnectionRJ45
PoE (Power-over-Ethernet)Yes
Remote ControlYes

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the NVR have spare SATA ports for an extra hard drive?

The NVR includes two SATA ports and one is already occupied by the pre-installed 4TB drive, so you can add one more HDD up to 6TB.

Will the 16 included PoE cameras work with an older non-PoE switch I already own?

The cameras need PoE power from the NVR's built-in PoE ports; a non-PoE switch cannot supply power, so you would need a separate PoE injector or switch for each camera.

How can I confirm the system is recording in 4K after I connect the cameras?

Check the NVR's live view or playback on an HDMI monitor — each channel should show 3840x2160 resolution at up to 30 FPS when recording is active.
