A black box NVR with four white bullet cameras and cables

Reolink

Reolink RLK8-520D4 8CH 5MP PoE NVR Kit 2TB

SKU CH-4EDC-GYRC9

An 8-channel PoE NVR kit with four 5MP cameras, person and vehicle detection, a pre-installed 2TB hard drive and up to 100ft night vision

  • TypeNVR Kit
  • Camera TypeIP Camera
  • Camera inputs8 Channel
  • Video InputPoE IP camera x 8
  • Audio InputCameras with built-in mic
  • Recording CompressionH.264, H.265
  • 5MP HD detail captures evidence clearly
  • Smart person/vehicle detection cuts false alerts
  • One-way audio records sound with built-in mic
  • 2TB pre-installed HDD supports 24/7 recording
  • PoE plug-and-play setup works indoors or outdoors

Eight-Channel 5MP PoE Kit

The Reolink RLK8-520D4 is an eight-channel network video recorder kit supplied with four wired 5MP PoE cameras for indoor or outdoor use. It targets homeowners and small businesses that want a complete, pre-configured surveillance system with person and vehicle detection to reduce false alerts from animals or foliage.

2TB Pre-Installed Expandable to 12TB

The NVR ships with a 2TB hard drive installed and supports up to 12TB total using two drives of 6TB each. That capacity provides weeks of continuous 5MP recording across four cameras; adding more cameras or raising the bitrate will consume space faster and may require the additional drives.

Fanless NVR Runs Silent on 48V DC

The recorder draws 48V DC at 1.875 to 2.5A from the included supply and operates without a fan, so it adds no audible noise to a living space or office. The PoE cameras are rated IP66 and function from -10°C to 55°C, handling rain, heat and cold without active cooling.

Highlights

  • 5MP HD detail captures evidence clearly
  • Smart person/vehicle detection cuts false alerts
  • One-way audio records sound with built-in mic
  • 2TB pre-installed HDD supports 24/7 recording
  • PoE plug-and-play setup works indoors or outdoors

Specifications

BrandReolink
Series8CH NVR Kit
ModelRLK8-520D4
TypeNVR Kit
Camera TypeIP Camera
Camera inputs8 Channel
Video InputPoE IP camera x 8
Audio InputCameras with built-in mic
Recording CompressionH.264, H.265
Video OutputVGA, HDMI
Audio Output1-channel, RCA
Resolution Display• HDMI: 4096*3072, 3840*2160, 1920*1080, 1440*900, 1280*1024, 1280*720, 1024*768 • VGA: 1920*1080, 1440*900, 1280*1024, 1280*800, 1280*720, 1024*768
Interface2 x USB 2.0
Built-In HDDBuilt-in 2TB; Up to 12TB (Max. 6TB capacity for each HDD)
Storage Capacity2TB HDD
Network ConnectionRJ45
Network ProtocolHTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
Network RemoteReolink App/Client; Edge, Firefox, Chrome, Safari
Operating SystemPC: Windows, Mac OS; SmartPhone: iOS, Android
Power SupplyDC 48V/1.875-2.5A
PoE (Power-over-Ethernet)Yes
Bundled Camera Number4
Camera Horizontal Resolution5 MP

Questions about this item

Will the 8-channel NVR still have free ports if I keep four existing PoE cameras?

The NVR accepts eight PoE IP cameras total, so four existing units would leave four channels open for the included 5MP cameras.

How can I verify the 5MP cameras are recording at full resolution after setup?

Connect a monitor via HDMI and confirm the live view shows 3840×2160 or 4096×3072 output, then check playback for H.265 5MP streams.

Does the box contain all cables for the four cameras or must I buy Ethernet leads separately?

The kit is described as plug-and-play with everything needed; the four wired PoE cameras connect directly to the NVR ports using the supplied cables.
