Rectangular black 2.5 inch SATA SSD with silver label and gold edge connector

SAMSUNG

SAMSUNG 870 QVO MZ-77Q8T0B/AM 8TB 2.5" SATA III internal SSD

SKU CH-MX67-6KE1X MPN MZ-77Q8T0B/AM

An 8 TB 2.5" SATA III solid-state drive using Samsung 4-bit QLC V-NAND with AES 256-bit encryption, up to 560 MB/s sequential read and 2,880 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form Factor2.5"
  • Capacity8TB
  • Memory ComponentsSamsung 4-bit QLC V-NAND
  • InterfaceSATA III

Options 8TB

  • 8 TB capacity stores massive media libraries
  • Sequential read up to 560 MB/s speeds up boot and load times
  • AES 256-bit encryption with TCG Opal 2.0 protects sensitive data
  • 2880 TBW endurance rating supports heavy daily workloads
  • 5 inch SATA form factor fits most laptops and desktops

8TB SATA III QLC drive

The Samsung 870 QVO MZ-77Q8T0B/AM is an internal solid state drive with an 8TB capacity and a 2.5 inch form factor. It uses Samsung 4-bit QLC V-NAND and a MKX controller on a SATA III interface. The drive targets desktop PC and laptop users who need large storage volumes for consumer workloads.

Upgrade from hard drives or smaller SSDs

Replacing a mechanical hard drive with this SSD removes moving parts and raises sequential speeds to 560 MBps read and 530 MBps write. The jump is worth it when a system supports the standard 2.5 inch SATA form factor and the user wants up to 2880 TBW of endurance with AES 256-bit encryption.

Sustained workload behaviour

Under continuous use the drive draws 2.2W on average and 4W at maximum while operating between 0°C and 70°C. Random performance reaches 98,000 IOPS read and 88,000 IOPS write at QD32, supported by a refined ECC algorithm. MTBF is rated at 1,500,000 hours for long-term reliability.

Highlights

  • 8 TB capacity stores massive media libraries
  • Sequential read up to 560 MB/s speeds up boot and load times
  • AES 256-bit encryption with TCG Opal 2.0 protects sensitive data
  • 2880 TBW endurance rating supports heavy daily workloads
  • 5 inch SATA form factor fits most laptops and desktops

Specifications

BrandSAMSUNG
Series870 QVO Series
ModelMZ-77Q8T0B/AM
Part NumberMZ-77Q8T0B/AM
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form Factor2.5"
Capacity8TB
Memory ComponentsSamsung 4-bit QLC V-NAND
InterfaceSATA III
ProtocolSATA
ControllerMKX
Cache0MB
EncryptionAES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive (IEEE1667)
Max Sequential ReadUp to 560 MBps
Max Sequential WriteUp to 530 MBps
4KB Random ReadRandom (QD1) [IOPS]: 11,000
Random (QD32) [IOPS]: 98,000
4KB Random WriteRandom (QD1) [IOPS]: 35,000
Random (QD32) [IOPS]: 88,000
MTBF1,500,000 hours
FeaturesReliability (TBW): 2880TBW
Power Consumption (Idle)30 mW
Power Consumption (Active)2.2W Average
4W Max
Operating Temperature0°C ~ +70°C
Height7.00mm
Width70.00mm
Depth100.00mm
Weight60.00g
Shipping weight0.10 kg
Package size165 × 94 × 20 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the 7 mm height 2.5 inch form factor fit my laptop drive bay?

The drive measures 7 mm tall, 70 mm wide and 100 mm deep, matching the standard 2.5 inch SATA enclosure used in most laptops and desktops.

Do I need a SATA data cable and a SATA power connector to install the MZ-77Q8T0B/AM?

Yes, connect a SATA data cable to the motherboard and a SATA power lead from the PSU; the step often missed is securing the drive with screws so the connectors stay seated.

How many terabytes can be written before the 8 TB QLC V-NAND reaches its endurance rating?

The drive is rated for 2880 TBW, after which the memory cells may no longer reliably retain data.
