Green rectangular M.2 2280 circuit board with black controller and silver Samsung label

SAMSUNG

SAMSUNG 950 PRO M.2 2280 512GB PCI-Express 3.0 x4 internal SSD MZ-V5P512BW

SKU CH-K8GN-HDZ64 MPN MZ-V5P512BW

Refurbished M.2 2280 internal SSD with 512GB MLC storage, PCI-Express 3.0 x4 interface, up to 2500 MBps read and 1500 MBps write speeds, plus 512MB DRAM cache

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity512GB
  • Memory ComponentsMLC
  • InterfacePCI-Express 3.0 x4
  • Fast boot and load times with up to 2500 MBps sequential read
  • Responsive multitasking backed by up to 300000 IOPS random read at QD32
  • Quick file saves and installs via up to 1500 MBps sequential write
  • Smooth heavy workloads sustained by 512MB DRAM cache and MLC endurance
  • Compact M.2 2280 form factor fits laptops and desktops with PCI-Express 3.0 x4 slots

Capacity and audience

This 512GB M.2 2280 drive uses MLC flash and a PCI-Express 3.0 x4 link to serve professionals who need sustained throughput for heavy workloads. The Samsung UBX controller and 512MB DRAM cache keep latency low during long sessions.

Sustained load behaviour

Sequential writes reach 1500 MBps and random writes hit 110,000 IOPS at QD32, so performance does not collapse once the SLC buffer fills. Average active power stays at 5.7W with a 7.0W burst ceiling, and the drive is rated for 0°C to 70°C operation.

Deciding specification

The MLC memory components deliver 1,500,000 hours MTBF and 43,000 IOPS random write at QD1, a combination that determines whether the drive meets professional endurance requirements.

Highlights

  • Fast boot and load times with up to 2500 MBps sequential read
  • Responsive multitasking backed by up to 300000 IOPS random read at QD32
  • Quick file saves and installs via up to 1500 MBps sequential write
  • Smooth heavy workloads sustained by 512MB DRAM cache and MLC endurance
  • Compact M.2 2280 form factor fits laptops and desktops with PCI-Express 3.0 x4 slots

Specifications

BrandSAMSUNG
Series950 PRO
ModelMZ-V5P512BW
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity512GB
Memory ComponentsMLC
InterfacePCI-Express 3.0 x4
ControllerSamsung UBX controller
Cache512MB DRAM
Max Sequential ReadUp to 2500 MBps
Max Sequential WriteUp to 1500 MBps
4KB Random ReadUp to 300,000 IOPS (4KB, QD32)
Up to 12,000 IOPS (4KB, QD1)
4KB Random WriteUp to 110,000 IOPS (4KB, QD32)
Up to 43,000 IOPS (4KB, QD1)
MTBF1,500,000 hours
FeaturesLevel up to unmatched performance, power efficiency and endurance
If you're a heavy workload professional searching for an SSD with uncompromising power and performance, look no further. The next-generation Samsung 950 PRO delivers exceptional performance for professionals.
This cutting-edge V-NAND-based NVMe SSD supports PCI Express Gen 3 x4 lanes, providing a higher bandwidth and lower latency to process a massive amount more data than SATA SSDs. Presented in a compact M.2 form factor, the future-oriented 950 PRO is ideal for professionals using high-end PCs and workstations.
Exper
Power Consumption (Active)Average: 5.7W
Maximum: 7.0W (Burst mode)
Operating Temperature0°C ~ +70°C
Max Shock Resistance1500G, duration 0.5m sec, 3 axis
Height2.38mm
Width22.15mm
Depth80.15mm
Weight10.00g
Package ContentSSD ONLY, NOTHIGN ELSE! SSD COMES IN PLAIN NON-RETAIL PACKAGE WITRHOUT ANY ACCESSORIES!
Shipping weight0.05 kg
Package size140 × 102 × 25 mm
