Green circuit board with black chips and silver label, M.2 2280 form factor

SAMSUNG

SAMSUNG 960 PRO MZ-V6P2T0BW 2TB internal SSD

SKU CH-0YP1-XDGWP MPN MZ-V6P2T0BW

M.2 2280 2TB internal SSD with PCI-Express 3.0 x4 interface, up to 3500 MBps sequential read and 2100 MBps write, plus AES 256-bit encryption

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • Memory Components3D NAND
  • InterfacePCI-Express 3.0 x4

Options 2TB

  • 2TB capacity stores large projects and libraries
  • PCI-Express 3.0 x4 interface delivers up to 3500 MBps sequential read
  • 1GB DRAM cache sustains up to 360000 IOPS random write
  • AES 256-bit encryption protects data at rest
  • 1500000 hours MTBF supports long-term reliability

2TB M.2 2280 NVMe SSD

The Samsung 960 PRO MZ-V6P2T0BW is a 2TB internal solid state drive built on 3D NAND with a Polaris controller and 1GB DRAM cache. It connects via PCI-Express 3.0 x4 in the M.2 2280 form factor. Sequential reads reach up to 3500 MBps and writes up to 2100 MBps.

Workstation and enthusiast workloads

This drive suits users who need sustained high throughput for large-file editing, heavy multitasking or demanding applications. Random read peaks at 440,000 IOPS (QD32) and random write at 360,000 IOPS (QD32). Buyers with lighter workloads or systems limited to slower interfaces may not utilise the full performance envelope.

PCI-Express 3.0 x4 interface requirement

The single specification that decides compatibility is the PCI-Express 3.0 x4 interface. The motherboard must provide an M.2 slot wired for four lanes of PCI-Express 3.0 to achieve the rated speeds. Without that connection the drive will not operate at its published sequential and random figures.

Highlights

  • 2TB capacity stores large projects and libraries
  • PCI-Express 3.0 x4 interface delivers up to 3500 MBps sequential read
  • 1GB DRAM cache sustains up to 360000 IOPS random write
  • AES 256-bit encryption protects data at rest
  • 1500000 hours MTBF supports long-term reliability

Specifications

BrandSAMSUNG
Series960 PRO
ModelMZ-V6P2T0BW
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
Memory Components3D NAND
InterfacePCI-Express 3.0 x4
ControllerSamsung Polaris controller
Cache1GB DRAM
Max Sequential ReadUp to 3500 MBps
Max Sequential WriteUp to 2100 MBps
4KB Random ReadUp to 440,000 IOPS (4KB, QD32)
Up to 14,000 IOPS (4KB, QD1)
4KB Random WriteUp to 360,000 IOPS (4KB, QD32)
Up to 50,000 IOPS (4KB, QD1)
MTBF1,500,000 hours
FeaturesTRIM Support: TRIM Supported
S.M.A.R.T Support: S.M.A.R.T Supported
GC (Garbage Collection): Auto Garbage Collection Algorithm
Encryption Support: AES 256-bit for User Data Encryption
Device Sleep Mode Support: 5mW (L1.2)
Power Consumption (Idle)40mW
Power Consumption (Active)5.8W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1500G, duration 0.5 msec, 3 axis
Height2.30mm
Width22.10mm
Depth80.00mm
Weight9.00g
Shipping weight0.05 kg
Package size145 × 102 × 28 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the M.2 2280 form factor fit my motherboard slot?

The drive uses the M.2 2280 form factor measuring 80.00mm long, 22.10mm wide and 2.30mm high, so it fits any standard M.2 2280 slot.

What is the correct way to install the PCI-Express 3.0 x4 drive and what step is often missed?

Insert the drive at an angle into the M.2 slot, press it flat and secure it with the motherboard screw; the step often missed is enabling the NVMe option in the BIOS so the OS sees the drive.

How long before the 3D NAND memory might need replacement under normal use?

The drive carries an MTBF of 1,500,000 hours and a 5-year limited warranty, indicating a very long service life before any replacement would be considered.
