Small green circuit board M.2 2280 SSD with black controller and gold edge connector

SAMSUNG

SAMSUNG 980 500GB M.2 2280 internal SSD

SKU CH-EDT5-GCM1M

A 500 GB M.2 2280 NVMe drive reaching 3100 MBps read and 2600 MBps write with 300 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity500GB
  • Memory ComponentsV-NAND 3-bit MLC
  • InterfacePCI-Express 3.0 x4, NVMe 1.4
  • Fast boot and load times with sequential reads up to 3100 MBps
  • Responsive multitasking from 470,000 IOPS random write at QD32
  • Data protected by AES 256-bit hardware encryption
  • Low 45 mW idle draw extends laptop battery life
  • Proven 1,500,000-hour MTBF and 300 TBW endurance

Samsung 980 500GB NVMe SSD

The Samsung 980 500GB is an internal solid state drive built for consumer desktops and laptops. It uses the M.2 2280 form factor and connects through a PCI-Express 3.0 x4 link with NVMe 1.4. The drive stores data on V-NAND 3-bit MLC memory managed by a Pablo controller.

500GB capacity for everyday workloads

This capacity suits operating systems, applications and active project files. Users who need space for large media libraries or extensive game collections should consider a higher-capacity drive. The 300 TBW endurance rating and 1.5 million hour MTBF support typical daily write cycles.

PCI-Express 3.0 x4 interface decides compatibility

The drive requires an M.2 slot wired for PCI-Express 3.0 x4 to deliver sequential reads up to 3100 MBps and writes up to 2600 MBps. Slots limited to fewer lanes or older protocols will reduce throughput. AES 256-bit encryption and TCG Opal support are included for data security.

Highlights

  • Fast boot and load times with sequential reads up to 3100 MBps
  • Responsive multitasking from 470,000 IOPS random write at QD32
  • Data protected by AES 256-bit hardware encryption
  • Low 45 mW idle draw extends laptop battery life
  • Proven 1,500,000-hour MTBF and 300 TBW endurance

Specifications

BrandSAMSUNG
Series980
ModelMZ-V8V500BW
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity500GB
Memory ComponentsV-NAND 3-bit MLC
InterfacePCI-Express 3.0 x4, NVMe 1.4
ControllerPablo
Max Sequential ReadUp to 3100 MBps
Max Sequential WriteUp to 2600 MBps
4KB Random ReadQD1: 17,000 IOPS
QD32: 400,000 IOPS
4KB Random WriteQD1: 54,000 IOPS
QD32: 470,000 IOPS
MTBF1,500,000 hours
Features300 TBW
TRIM Support: Supported
S.M.A.R.T Support: Supported
GC (Garbage Collection): Auto Garbage Collection Algorithm
Encryption Support: AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
Device Sleep Mode Support: Yes
Power Consumption (Idle)45 mW
Power Consumption (Active)Average: 4.3W
Maximum: 5.9W (Burst mode)
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,500G & 0.5 ms (Half sine)
Height2.38mm
Width22.15mm
Depth80.15mm
Weight8.00g

Questions about this item

How can I verify the 980 500GB is running at its rated 3100 MBps read speed after installation?

Use Samsung Magician or CrystalDiskMark to run a sequential read test; the drive should reach up to 3100 MBps on a PCIe 3.0 x4 slot with NVMe 1.4 enabled.

What comes with the MZ-V8V500BW and what must I supply myself?

The package contains the 500GB M.2 2280 drive only; you need a compatible M.2 slot, motherboard standoff screw and, if your board lacks integrated cooling, an aftermarket heatsink.

Which capacity of the 980 series should I choose for a 300 TBW endurance rating?

The 500GB model provides the 300 TBW rating; other capacities in the 980 line have different endurance figures, so select 500GB when that write endurance is required.
