Green printed circuit board with black label and gold edge connector

SAMSUNG

SAMSUNG 980 M.2 2280 1TB internal SSD MZ-V8V1T0B/AM

SKU CH-DE0P-NZ3XG MPN MZ-V8V1T0B/AM

1TB M.2 2280 NVMe SSD with sequential speeds up to 3500/3000 MB/s and 600TB endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory ComponentsV-NAND MLC
  • InterfacePCI-Express 3.0 x4, NVMe 1.4

Options 1TB

  • Up to 3500 MB/s sequential read accelerates game loads
  • Up to 3000 MB/s sequential write speeds large file saves
  • 600 TBW endurance rating supports heavy daily workloads
  • AES 256-bit encryption with TCG/Opal 2.0 protects stored data
  • Intelligent TurboWrite 2.0 expands SLC buffer up to 5.5 times for sustained speed

Samsung 980 1TB NVMe SSD

The Samsung 980 1TB drive uses a PCI-Express 3.0 x4 interface with NVMe 1.4 protocol. It is built for consumer workloads such as gaming and heavy graphics workflows. The controller is named Pablo and the memory is V-NAND MLC.

Sustained load behaviour

Intelligent TurboWrite 2.0 enlarges the TurboWrite region up to 5.5 times to maintain write speeds. Full Power Mode via Magician 6.3 keeps the drive at peak performance continuously. Host Memory Buffer links host DRAM directly to the controller to overcome DRAMless constraints.

Thermals noise and power

Nickel coating on the controller and a heat spreader label on the NAND provide thermal control. Samsung's thermal algorithm manages heat to minimise performance fluctuations during extended use. Idle power consumption is 45 mW.

Highlights

  • Up to 3500 MB/s sequential read accelerates game loads
  • Up to 3000 MB/s sequential write speeds large file saves
  • 600 TBW endurance rating supports heavy daily workloads
  • AES 256-bit encryption with TCG/Opal 2.0 protects stored data
  • Intelligent TurboWrite 2.0 expands SLC buffer up to 5.5 times for sustained speed

Specifications

BrandSAMSUNG
Series980
ModelMZ-V8V1T0B/AM
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory ComponentsV-NAND MLC
InterfacePCI-Express 3.0 x4, NVMe 1.4
ProtocolNVMe 1.4
ControllerPablo
EncryptionAES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive (IEEE1667)
Max Sequential ReadUp to 3500 MBps
Max Sequential WriteUp to 3000 MBps
4KB Random ReadQD1: 17,000 IOPS
QD32: 500,000 IOPS
4KB Random WriteQD1: 54,000 IOPS
QD32: 480,000 IOPS
Terabytes Written (TBW)600TB
MTBF1,500,000 hours
FeaturesSOLID PERFORMANCE
- Solid performance with Seq. Read/Write speeds up to 3,500/3,000 MB/s
- Intelligent TurboWrite 2.0 maximize full potential performance with enlarged TurboWrite region up to 5.5 times
- Host Memory Buffer (HMB) links DRAM in the host directly to the 980 to overcome performance restrain from DRAMless
- Full Power Mode through Magician 6.3 allows the 980 to run at peak level for nonstop for a consistent high performance
PROVEN RELIABILITY
- Uncompromising endurance with reliability up to 600TBW
- Thermal control solution provides 50% less heat vs. the 970 EVO
OPTIMIZE
Power Consumption (Idle)45 mW
Power Consumption (Active)4.6W
Max Shock Resistance1500G & 0.5 ms (Half sine)
Height2.38mm
Width22.15mm
Depth80.15mm
Shipping weight0.07 kg
Package size142 × 97 × 19 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much power does the 980 draw when the system is idle for long periods?

Idle power consumption is 45 mW, so the drive adds minimal heat and keeps laptop battery drain low during all-day use.

What motherboard slot and protocol are required for this MZ-V8V1T0B/AM to function?

It needs an M.2 2280 slot wired for PCI-Express 3.0 x4 with NVMe 1.4 support; the drive is DRAM-less and uses Host Memory Buffer, so the platform must provide system RAM for that feature.

Will the 980 work in an older board limited to PCI-Express 3.0 x4?

Yes, the interface is PCI-Express 3.0 x4, so it runs at its rated 3500 MB/s read and 3000 MB/s write on such boards; the Pablo controller and nickel-coated thermal management keep performance steady during sustained loads.
