Samsung 990 EVO Plus M.2 2280 internal SSD with green circuit board and black label

SAMSUNG

SAMSUNG 990 EVO Plus MZ-V9S2T0B/AM 2TB internal SSD

SKU CH-5DZE-75N49 MPN MZ-V9S2T0B/AM

M.2 2280 NVMe drive with PCIe 4.0 x4 and PCIe 5.0 x2 support, up to 7250 MB/s read and 6300 MB/s write, 1200 TBW endurance and 256-bit AES encryption

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • InterfacePCI-Express 4.0 x4 / PCI-Express 5.0 x2
  • ProtocolNVMe 2.0

Style Faster

Options 2TB

  • Sequential read up to 7250 MB/s for fast large-file loads
  • Sequential write up to 6300 MB/s speeds up content creation
  • Random read 1000000 IOPS and random write 1350000 IOPS for snappy multitasking
  • 1200 TBW endurance rating supports heavy daily workloads
  • Nickel-coated controller keeps drive cool at 4.6W read and 4.2W write

Dual-link PCIe 4.0 x4 and 5.0 x2

The Samsung 990 EVO Plus MZ-V9S2T0B/AM is a 2TB internal SSD built for consumer PCs and laptops. It uses the M.2 2280 form factor and connects through a dual-mode interface that negotiates either PCIe 4.0 x4 or PCIe 5.0 x2 links. The drive runs on the NVMe 2.0 protocol and relies on Host Memory Buffer technology instead of a dedicated DRAM cache.

Sustained throughput with nickel-coated controller

Sequential reads reach up to 7250 MBps and writes up to 6300 MBps, while 4KB random performance tops out at 1000000 read and 1350000 write IOPS. Intelligent TurboWrite 2.0 maintains high speeds across large file transfers. A nickel-coated controller improves thermal efficiency, keeping active power draw at 4.6W during reads and 4.2W during writes for consistent output under load.

Hardware encryption and 1200 TBW endurance

The drive supports 256-bit AES encryption with TCG Opal v2.0 and MS eDrive (IEEE1667) for hardware-based data protection. Rated endurance is 1200 TBW, reflecting the write capacity guaranteed over the product life. Samsung Magician software provides firmware updates and health monitoring to maintain performance over time.

Highlights

  • Sequential read up to 7250 MB/s for fast large-file loads
  • Sequential write up to 6300 MB/s speeds up content creation
  • Random read 1000000 IOPS and random write 1350000 IOPS for snappy multitasking
  • 1200 TBW endurance rating supports heavy daily workloads
  • Nickel-coated controller keeps drive cool at 4.6W read and 4.2W write

Specifications

BrandSAMSUNG
Series990 EVO Plus
ModelMZ-V9S2T0B/AM
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
InterfacePCI-Express 4.0 x4 / PCI-Express 5.0 x2
ProtocolNVMe 2.0
CacheNo DRAM (HMB)
EncryptionClass 0 (AES 256) , TCG/Opal v2.0, MS eDrive (IEEE1667)
Max Sequential ReadUp to 7250 MBps
Max Sequential WriteUp to 6300 MBps
4KB Random ReadUp to 1,000,000 IOPS
4KB Random WriteUp to 1,350,000 IOPS
Terabytes Written (TBW)1200TB
Power Consumption (Active)4.6W / 4.2W (Read / Write)
Shipping weight0.05 kg
Package size159 × 102 × 13 mm

Other versions of this model

4 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much power does the 990 EVO Plus draw during sustained read and write workloads?

The drive consumes 4.6W during active reads and 4.2W during active writes, while the nickel-coated controller helps manage heat without a heatsink.

Does my motherboard need a specific M.2 slot key or PCIe generation to run this 2TB drive?

It fits any M.2 2280 slot and negotiates PCIe 4.0 x4 or PCIe 5.0 x2 automatically; an NVMe-capable BIOS is the only requirement.

Will the 990 EVO Plus work reliably in a laptop that only supports PCIe 3.0?

Yes, the NVMe 2.0 interface is backward compatible with PCIe 3.0 x4 slots, though sequential speeds will be limited to the slot's maximum bandwidth.
