Silver 2.5 inch U.2 enterprise SSD with label

SAMSUNG

SAMSUNG MZ-QL296000 960GB enterprise SSD

SKU CH-WQBD-SPCTB MPN MZ-QL296000

A 960 GB enterprise U.2 drive delivering 6500 MB/s reads and 1 DWPD endurance for PCIe 4.0 servers

  • Form Factor2.5" U.2
  • Capacity960GB
  • Memory ComponentsV-NAND TLC
  • InterfacePCIe 4.0 x4 NVMe 1.4
  • ControllerSamsung Elpis Controller
  • CacheSamsung Low Power SDRAM

Options 960GB

Struck-through versions exist but are not stocked here.

  • Fast sequential reads up to 6500 MBps with PCIe 4.0 x4 NVMe 1.4
  • Sustained write performance up to 1500 MBps for heavy workloads
  • High random read IOPS up to 580000 for responsive database access
  • Enterprise endurance rated at 1 DWPD and 1752 TBW
  • 256-bit AES encryption protects data at rest

960GB U.2 enterprise SSD

The Samsung PM9A3 is a 960GB enterprise solid-state drive in a 2.5-inch U.2 form factor. It uses V-NAND TLC memory with a Samsung Elpis controller and low-power SDRAM cache. Designed for servers and storage arrays that need consistent throughput and 1 DWPD endurance. New condition.

PCIe 4.0 x4 NVMe 1.4 interface limits

The drive connects through a PCIe 4.0 x4 link using NVMe 1.4. Maximum sequential read reaches 6500 MBps while sequential write tops out at 1500 MBps. Random 4KB read performance is rated at 580,000 IOPS and random write at 70,000 IOPS. These figures are bound by the four-lane PCIe 4.0 interface.

1 DWPD endurance decides fit

The drive is warranted for 1 drive write per day, equating to 1,752 TBW over its lifetime. MTBF is rated at 2,000,000 hours. Active power draw is 9.5W for reads and 8.0W for writes with 3.5W idle. Buyers who need higher write endurance or multiple drive writes per day should look elsewhere.

Highlights

  • Fast sequential reads up to 6500 MBps with PCIe 4.0 x4 NVMe 1.4
  • Sustained write performance up to 1500 MBps for heavy workloads
  • High random read IOPS up to 580000 for responsive database access
  • Enterprise endurance rated at 1 DWPD and 1752 TBW
  • 256-bit AES encryption protects data at rest

Specifications

BrandSAMSUNG
ModelPM9A3
Part NumberMZ-QL296000
Form Factor2.5" U.2
Capacity960GB
Memory ComponentsV-NAND TLC
InterfacePCIe 4.0 x4 NVMe 1.4
ControllerSamsung Elpis Controller
CacheSamsung Low Power SDRAM
Max Sequential ReadUp to 6500 MBps
Max Sequential WriteUp to 1500 MBps
4KB Random ReadUp to 580,000 IOPS
4KB Random WriteUp to 70,000 IOPS
Endurance1 DWPD
MTBF2,000,000 hours
Features1,752 TBW
Power Consumption (Idle)3.5W
Power Consumption (Active)Read/Write: 9.5W / 8.0W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,500G & 0.5 ms (Half sine)
Height7.00mm
Width69.85mm
Depth100.20mm
Weight90.00 g
Shipping weight0.18 kg
Package size178 × 127 × 15 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What capacity does the PM9A3 MZ-QL296000 provide?

The drive provides 960GB of usable storage in a single 2.5" U.2 form factor.

How does the 6500 MBps sequential read translate to real workloads?

Large-file reads such as backup streams or video ingest can approach 6500 MBps when the host PCIe 4.0 x4 link is saturated.

What does the PCIe 4.0 x4 NVMe 1.4 interface cap in practice?

The x4 lane width limits peak throughput to the PCIe 4.0 x4 maximum, so sequential reads top out at 6500 MBps and writes at 1500 MBps.
