Triple-fan ATX graphics card, matte black shroud with silver accents, 300 mm long, 2.7-slot width

Sapphire Tech

Sapphire Tech NITRO+ Radeon RX 9060 XT 11350-01-20G graphics card

SKU CH-X8J7-2A2D5 MPN 11350-01-20G

PCI Express 5.0 x16 graphics card with AMD Radeon RX 9060 XT GPU, 16GB GDDR6 memory, 3320 MHz boost clock and triple-fan cooling in a 300 mm ATX form factor

  • InterfacePCI Express 5.0 x16
  • Chipset ManufacturerAMD
  • GPU SeriesAMD Radeon RX 9000 Series
  • GPURadeon RX 9060 XT
  • ArchitectureRDNA 4
  • Game Clock2780 MHz
  • 16 GB GDDR6 memory at 20 Gbps for high-resolution textures
  • Boost clock reaches 3320 MHz for responsive frame rates
  • PCI Express 5.0 x16 interface doubles host bandwidth
  • Triple-fan cooler on a 300 mm ATX card keeps thermals in check
  • HDMI and DisplayPort 2.1a drive up to three 8K displays

Sapphire NITRO+ RX 9060 XT 16GB Graphics Card

The Sapphire NITRO+ Radeon RX 9060 XT is a PCI Express 5.0 x16 graphics card built on the AMD RDNA 4 architecture. It targets 1440p gaming and content creation with 2048 stream processors and a 3320 MHz boost clock. The 16GB GDDR6 frame buffer runs across a 128-bit bus at 20 Gbps. Display outputs comprise two HDMI ports and one DisplayPort 2.1a connector.

Triple-Fan Cooling 182W TDP 450W PSU

A triple-fan cooler dissipates the 182 W thermal design power while keeping acoustic levels low in typical gaming loads. The card draws auxiliary power through a single 8-pin connector, and Sapphire recommends a 450 W power supply for stable operation. The 2.7-slot ATX form factor fits most mid-tower cases without obstructing adjacent expansion slots.

128-Bit Memory Interface 20 Gbps GDDR6

The 128-bit memory interface combined with 20 Gbps GDDR6 sets the bandwidth ceiling for this model. That specification determines whether the card can sustain high frame rates at 1440p or 4K in memory-intensive titles. Buyers should match this bandwidth profile to their target resolution and texture quality settings before purchase.

Highlights

  • 16 GB GDDR6 memory at 20 Gbps for high-resolution textures
  • Boost clock reaches 3320 MHz for responsive frame rates
  • PCI Express 5.0 x16 interface doubles host bandwidth
  • Triple-fan cooler on a 300 mm ATX card keeps thermals in check
  • HDMI and DisplayPort 2.1a drive up to three 8K displays

Specifications

BrandSAPPHIRE
SeriesNITRO+
Model11350-01-20G
Part Number11350-01-20G
InterfacePCI Express 5.0 x16
Chipset ManufacturerAMD
GPU SeriesAMD Radeon RX 9000 Series
GPURadeon RX 9060 XT
ArchitectureRDNA 4
Game Clock2780 MHz
Boost Clock3320 MHz
Stream Processors2048
Effective Memory Clock20000 MHz (20 Gbps)
Memory Size16GB
Memory Interface128-Bit
Memory TypeGDDR6
DirectXDirectX 12 Ultimate
Multi-Monitor Support3
HDMI2 x HDMI
DisplayPort1x DisplayPort™ 2.1a
Max Resolution7680 x 4320
CoolerTriple Fans
Thermal Design Power182W
Recommended PSU Wattage450W
Power Connector8-Pin
HDCP ReadyYes
Form FactorATX
Max GPU Length300 mm
Card Dimensions (L x H)300 x 131 x 55 mm
Slot Width2.7 Slots
Shipping weight1.61 kg
Package size432 × 254 × 89 mm

Questions about this item

How do I install the 11350-01-20G and what step is often missed?

Seat the card in a PCI Express 5.0 x16 slot, connect the 8-Pin power connector, and secure the 2.7-slot bracket; the step often missed is confirming the PSU delivers the recommended 450 W.

What maintenance or replacement will the 11350-01-20G need later?

The triple-fan cooler should be dusted periodically; the 16 GB GDDR6 memory and GPU are not user-serviceable, so no component replacement is expected during normal life.

What limit appears first on the 11350-01-20G under sustained load?

The 182 W thermal design power and 128-bit memory interface set the practical ceiling; the cooler must dissipate 182 W continuously while the 20 Gbps memory bandwidth caps sustained throughput.
