Green printed circuit board M.2 2280 SSD with black controller and silver NAND chips

Seagate

Seagate FireCuda 530R ZP1000GM3A063 1TB internal SSD

SKU CH-6E2H-1CJAW MPN ZP1000GM3A063

1TB M.2 2280 PCIe 4.0 x4 NVMe SSD delivering 7400 MB/s reads, 7000 MB/s writes and 1100 TBW endurance

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory Components3D NAND TLC
  • InterfacePCI-Express 4.0 x4
  • Up to 7400 MBps sequential read for fast game loading
  • Up to 7000 MBps sequential write for quick file saves
  • 1100 TBW endurance rating for long-term reliability
  • 1,300,000 IOPS random read for responsive multitasking
  • PCIe 4.0 x4 interface enables high-throughput performance

FireCuda 530R 1TB NVMe SSD

The Seagate FireCuda 530R ZP1000GM3A063 is a 1TB internal solid state drive built for consumer workloads. It uses an M.2 2280 form factor with 3D NAND TLC memory and a DRAM cache. The drive targets gamers and content creators who need fast, reliable storage.

PCIe 4.0 x4 interface

The single specification that determines compatibility is the PCI-Express 4.0 x4 NVMe interface. Your motherboard must provide an M.2 slot wired for PCIe 4.0 x4 to reach the advertised performance. Older slots will work but limit throughput to their own maximum.

1TB capacity with 1100 TBW endurance

The 1TB capacity holds large game libraries, project files and media collections with room to spare. Sequential reads reach 7400 MBps and writes reach 7000 MBps, while random 4KB performance hits 1,300,000 IOPS. The 1100 TBW rating and 1,800,000 hour MTBF provide headroom for heavy daily writes over many years.

Highlights

  • Up to 7400 MBps sequential read for fast game loading
  • Up to 7000 MBps sequential write for quick file saves
  • 1100 TBW endurance rating for long-term reliability
  • 1,300,000 IOPS random read for responsive multitasking
  • PCIe 4.0 x4 interface enables high-throughput performance

Specifications

BrandSeagate
SeriesFireCuda 530R
ModelZP1000GM3A063
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory Components3D NAND TLC
InterfacePCI-Express 4.0 x4
Max Sequential ReadUp to 7400 MBps
Max Sequential WriteUp to 7000 MBps
4KB Random ReadUp to 1,300,000 IOPS
4KB Random WriteUp to 1,300,000 IOPS
Terabytes Written (TBW)1100TB
MTBF1,800,000 hours
HeatSinkwithout HeatSink
FeaturesPeak Performance
Level up with ultra-fast PCIe Gen4 SSD speeds for accelerated gaming and content creation
Easy Gaming
Supports Microsoft's DirectStorage technology for faster load times
Tough Stuff
Extremely durable, with endurance of up to 5,050TBW
Power Consumption (Idle)22mW
Power Consumption (Active)8.3W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1500G
Height2.23mm
Width22.15mm
Depth80.15mm
Weight7.3g
Shipping weight0.09 kg
Package size156 × 112 × 25 mm

Questions about this item

What does the 7400 MBps sequential read mean for actual game load times?

The 7400 MBps peak read speed feeds data to the CPU fast enough to cut level-load screens noticeably when the game engine can stream assets directly from the NVMe drive.

How does the PCIe 4.0 x4 interface limit real-world throughput?

PCIe 4.0 x4 caps theoretical bandwidth near 8 GBps so the drive's 7400 MBps read and 7000 MBps write sit at the practical ceiling of the link.

Will the M.2 2280 board fit my laptop slot without a heatsink?

The 2280 form factor is 80 mm long and the drive ships without a heatsink so it fits standard M.2 slots that have no extra vertical clearance.
