Green rectangular M.2 2280 circuit board with black controller and NAND chips, no heatsink

Seagate

Seagate FireCuda 540 ZP1000GM3A004 1TB internal SSD

SKU CH-X7D7-C1V8J MPN ZP1000GM3A004

1TB M.2 2280 internal SSD with PCI-Express 5.0 x4 interface delivering up to 9500 MBps read and 8500 MBps write speeds for demanding gaming and creative workloads

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory Components3D TLC
  • InterfacePCI-Express 5.0 x4
  • Fast game loads with DirectStorage support
  • Sequential reads up to 9500 MBps
  • Sequential writes up to 8500 MBps
  • Random reads up to 1300000 IOPS
  • Random writes up to 1500000 IOPS

Seagate FireCuda 540 1TB PCIe 5.0 SSD

The Seagate FireCuda 540 is a 1TB internal solid-state drive built on the PCI-Express 5.0 x4 interface with NVME protocol. It uses 3D TLC memory to deliver sequential reads up to 9500 MBps and writes up to 8500 MBps. The drive targets enthusiasts and content creators who need high throughput for large project files and modern DirectStorage-enabled titles.

Thermals noise and power

Without a heatsink the drive relies on motherboard cooling to manage thermals during sustained workloads. Active power draw is rated at 10W while idle consumption sits at 144 mW. The M.2 2280 form factor produces no audible noise because it has no moving parts.

Bundle and software impact

The package includes three years of Rescue Data Recovery Services and a five-year limited warranty. These services provide a path to professional recovery if the drive fails and extend the standard coverage period. No additional software utilities or mounting hardware are mentioned in the specifications.

Highlights

  • Fast game loads with DirectStorage support
  • Sequential reads up to 9500 MBps
  • Sequential writes up to 8500 MBps
  • Random reads up to 1300000 IOPS
  • Random writes up to 1500000 IOPS

Specifications

BrandSeagate
SeriesFireCuda 540
ModelZP1000GM3A004
Part NumberZP1000GM3A004
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory Components3D TLC
InterfacePCI-Express 5.0 x4
ProtocolNVMe 2.0
Max Sequential ReadUp to 9500 MBps
Max Sequential WriteUp to 8500 MBps
4KB Random ReadUp to 1,300,000 IOPS
4KB Random WriteUp to 1,500,000 IOPS
MTBF1,800,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)144(mW)
Power Consumption (Active)10W
Shipping weight0.06 kg
Package size155 × 108 × 24 mm

Questions about this item

How do I install the M.2 2280 drive and what step is often missed?

Insert the M.2 2280 module into a PCI-Express 5.0 x4 slot at a 30-degree angle, secure it with the motherboard screw, then enable NVMe 2.0 in BIOS; the step most people miss is checking that the slot runs at Gen 5 speed rather than falling back to Gen 4.

What maintenance or replacement will the 3D TLC 1TB drive need later?

No scheduled maintenance is required; monitor health via SMART tools and replace the drive if the media‑wear indicator approaches 100 % or if the MTBF rating of 1800000 hours is exceeded in critical workloads.

What limit appears first during sustained heavy writes on this PCI-Express 5.0 x4 SSD?

The controller will throttle once the NAND temperature rises under continuous 8500 MBps writes, reducing sequential throughput to protect the 3D TLC memory and keep power draw near the 10 W active rating.
