Silverstone
SilverStone Strider Essential SST-ST70F-ES230 700W power supply
A 700 W ATX12V power supply with 80 PLUS certification, active PFC above .9, a single +12 V rail rated at 54 A, and a 120 mm fan rated from 18 dBA
- TypeATX12V
- Maximum Power700 W
- FansSingle 120mm silent fan 18 dBA minimum
- PFCActive PFC (PF>0.9 at full load)
- +12V RailsSingle
- Efficiency82% - 85% at 20% - 100% loading
- 700 W output powers demanding builds
- 80 PLUS certified efficiency between 82% and 85%
- Single +12 V rail delivers 54 A for stable GPU power
- 120 mm fan runs as low as 18 dBA for quiet operation
- Active PFC achieves power factor above .9 at full load
Essential power for mainstream builds
The SilverStone Strider Essential SST-ST70F-ES230 delivers 700 W of continuous power from a single +12 V rail rated at 54 A. It carries 80 PLUS certification with 82–85 % efficiency across 20–100 % loading and active PFC above .9 at full load. A 120 mm fan runs at a minimum of 18 dBA for quiet home or office use.
Upgrade from lower-wattage or group-regulated units
This unit replaces older supplies that cannot sustain 700 W at 40 °C or that split the +12 V output across multiple rails. The jump is worth it when a graphics card demands an 8-pin and 6-pin PCIe connector pair and the system must run 24/7 without derating. Builders staying with entry-level GPUs or integrated graphics will not need this headroom.
Fits standard ATX cases with 180–264 V input
The 150 mm depth and 24-pin, EPS, four PCIe, four SATA and three peripheral connectors cover typical mid-tower layouts. Cables reach 500 mm for the motherboard and 750 mm for the CPU power plug. Over-voltage and short-circuit protection guard connected components. Systems requiring redundant supplies or server-grade voltage ranges are not addressed by this design.
Highlights
- 700 W output powers demanding builds
- 80 PLUS certified efficiency between 82% and 85%
- Single +12 V rail delivers 54 A for stable GPU power
- 120 mm fan runs as low as 18 dBA for quiet operation
- Active PFC achieves power factor above .9 at full load
Specifications
| Brand | SilverStone |
|---|---|
| Series | Strider Series |
| Model | SST-ST70F-ES230 |
| Type | ATX12V |
| Maximum Power | 700 W |
| Fans | Single 120mm silent fan 18 dBA minimum |
| PFC | Active PFC (PF>0.9 at full load) |
| +12V Rails | Single |
| Efficiency | 82% - 85% at 20% - 100% loading |
| Energy-Efficient | 80 PLUS Certified |
| Input Voltage | 180V - 264V |
| Input Frequency Range | 47 - 63 Hz |
| Output | +3.3V@22A, +5V@22A, +12V@54A, [email protected] , [email protected] |
| MTBF | 100,000 hours |
| Connectors | 1 x 24 / 20-Pin motherboard connector (500mm) 1 x 8 / 4-Pin EPS / ATX 12V connector (750mm) 4 x 8 / 6-Pin PCIE connector ("500mm / 150mm" x 2) 4 x SATA connector ("500mm / 150mm" x 2) 3 x 4-Pin Peripheral connector (500mm / 150mm / 150mm) 1 x 4-Pin Floppy connector (500mm / 150mm / 150mm / 150mm) |
| Features | High efficiency with 80 PLUS certification 24/7 continuous power output with 40°C operating temperature Class-leading single +12V rail Active PFC Circuitry PCI-E 8pin and PCI-E 6pin connector support Silent running 120mm fan with 18dBA Power density: 388W per liter Color: Black (Lead-Free Paint) Operating temperature: 0°C - 40°C GPU Support list Compatible with ATX12V v2.4 |
| Dimensions | 3.39" x 5.91" x 5.51" |
| Weight | 3.15 lbs. |
| Over Voltage Protection | Yes |
| Short Circuit Protection | Yes |
| Over Power Protection | Yes |
Questions about this item
Will the 3.39 x 5.91 x 5.51 inch case fit in a standard ATX chassis?
The power supply measures 3.39 inches wide, 5.91 inches deep and 5.51 inches high, matching the standard ATX form factor used by most mid-tower and full-tower cases.
How do I connect the 8/4-pin EPS cable to my motherboard, and what is the common mistake?
Split the 8-pin block into two 4-pin halves if the board only has a 4-pin socket; the mistake is forcing the full 8-pin connector into a 4-pin header.
When should I expect to replace the 120mm fan rated for 100000 hours MTBF?
The fan is designed for 100000 hours of continuous operation at 40°C; in typical desktop use this translates to many years before a replacement is needed.
