Rectangular 2.5 inch SATA SSD with black metal casing and label

Solidigm

Solidigm D3-S4520 240GB 2.5" SATA enterprise SSD SSDSC2KB240GZ01

SKU CH-PT7T-GWGA4 MPN SSDSC2KB240GZ01

A 240 GB SATA enterprise SSD built with 144L TLC 3D NAND for server workloads

  • Form Factor2.5"
  • Capacity240GB
  • Memory Components144L TLC 3D NAND
  • InterfaceSATA III
  • MTBF2,000,000 hours
  • Operating Temperature0°C ~ +70°C
  • Enterprise reliability with 2,000,000 hours MTBF
  • Fast sequential reads up to 470 MB/s
  • Strong random read performance at 44,000 IOPS
  • Hardware-based 256-bit encryption protects data
  • Built for servers with 1,000 G shock resistance

Enterprise SATA SSD for 240GB server storage

The Solidigm D3-S4520 is a 2.5 inch internal drive built for data-centre and server workloads. It connects through a SATA III interface and uses 144L TLC 3D NAND to deliver 240GB of capacity. The drive is rated for 2,000,000 hours MTBF and operates between 0°C and 70°C.

Suited for read-heavy server arrays.

This SSD fits servers that need reliable sequential reads of 470 MB/s and random 4KB reads of 44,000 IOPS. Builders who need higher sustained write throughput or larger endurance than 1024 TBW should look at drives specified for those workloads.

1024 TBW endurance rating defines the write life

The drive warrants 1024 terabytes written over its lifetime, a figure that directly determines how long it can serve in mixed read-write server environments before wear-out.

Highlights

  • Enterprise reliability with 2,000,000 hours MTBF
  • Fast sequential reads up to 470 MB/s
  • Strong random read performance at 44,000 IOPS
  • Hardware-based 256-bit encryption protects data
  • Built for servers with 1,000 G shock resistance

Specifications

BrandSolidigm
ModelD3-S4520
Form Factor2.5"
Capacity240GB
Memory Components144L TLC 3D NAND
InterfaceSATA III
MTBF2,000,000 hours
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Shipping weight2.27 kg
Package size279 × 279 × 127 mm

Questions about this item

What does the 470 MB/s read speed mean for a server workload?

The 470 MB/s maximum read transfer rate is the peak sequential throughput the D3-S4520 can sustain over the SATA 6Gb/s link when the controller and queue depth allow it.

How does the SATA 6Gb/s interface limit this drive?

The SATA 6Gb/s interface caps practical throughput at the drive's rated 470 MB/s read and 233 MB/s write, well below the bus ceiling.

Will the 2.5 inch form factor fit a standard server drive bay?

Yes, the 2.5 inch form factor with a 0.3 inch height matches the common 7 mm server drive bay and caddy dimensions.
