Green rectangular circuit board with gold edge connector and black memory chips

Solidigm

Solidigm D3-S4520 240GB M.2 2280 SATA enterprise SSD SSDSCKKB240GZ01

SKU CH-6ERX-1CVED MPN SSDSCKKB240GZ01

Enterprise 240 GB SATA M.2 2280 SSD with 144L TLC 3D NAND, 2,000,000-hour MTBF and end-to-end data protection for server continuity

  • Form FactorM.2 2280
  • Capacity240GB
  • Memory Components144L TLC 3D NAND
  • InterfaceSATA III
  • MTBF2,000,000 hours
  • Operating Temperature0°C ~ +70°C
  • Enterprise reliability with 2,000,000 hours MTBF rating
  • End-to-end data protection guards against sudden power loss
  • 9x lower annualised failure rate reduces drive replacements
  • Firmware updates complete without server reset cutting downtime
  • M.2 2280 form factor fits dense server configurations

Solidigm D3-S4520 240GB SATA SSD

The Solidigm D3-S4520 is a 240GB enterprise solid-state drive built for data-centre servers. It uses a SATA III interface in an M.2 2280 form factor with 144L TLC 3D NAND. The drive targets workloads that demand consistent uptime and data integrity over raw capacity or peak throughput.

Suited for arrays needing endurance

This drive fits administrators who prioritise a 2,000,000-hour MTBF and firmware updates without a server reset. It operates from 0°C to 70°C and tolerates 1,000 G shock. Buyers who need larger capacities or a PCIe interface should consider other models.

SATA III interface dictates host compatibility

The single specification that decides fit is the SATA III interface. The motherboard or backplane must provide a SATA-connected M.2 slot; a PCIe-only M.2 slot will not work. Verify the host connector type before purchase.

Highlights

  • Enterprise reliability with 2,000,000 hours MTBF rating
  • End-to-end data protection guards against sudden power loss
  • 9x lower annualised failure rate reduces drive replacements
  • Firmware updates complete without server reset cutting downtime
  • M.2 2280 form factor fits dense server configurations

Specifications

BrandSolidigm
SeriesD3-S4520
ModelD3-S4520
Form FactorM.2 2280
Capacity240GB
Memory Components144L TLC 3D NAND
InterfaceSATA III
MTBF2,000,000 hours
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Shipping weight0.45 kg
Package size203 × 152 × 127 mm

Questions about this item

How do I install this M.2 2280 SATA SSD in a server and what step is often missed?

Insert the drive into an M.2 slot wired for SATA at a 20-degree angle, then secure it with the screw; the common mistake is using a slot that only supports PCIe, which will not detect the drive.

What maintenance or replacement will the 144L TLC 3D NAND need over its service life?

The 144L TLC 3D NAND has a finite write endurance; plan to replace the drive once its SMART media-wear indicator approaches the rated limit to avoid unexpected failure.

What limit appears first on this SSD during sustained heavy writes?

The SATA III interface caps sequential throughput at 6 Gb/s, so the bus saturates before the 144L TLC 3D NAND or thermal throttling at 70°C becomes the bottleneck.
