Rectangular E3.S 7.5mm SSD with green PCB and black label

Solidigm

Solidigm D7-PS1010 SB5PHA7X153T001 15.36TB E3.S 7.5mm PCIe 5.0 enterprise SSD

SKU CH-5CBE-36TZ5 MPN SB5PHA7X153T001

E3.S 7.5mm PCIe 5.0 enterprise SSD delivering 15.36TB capacity with sequential reads up to 14500 MBps and 1 DWPD endurance

  • Form FactorE3.S 7.5mm
  • Capacity15.36TB
  • Memory Components176L TLC 3D NAND
  • InterfacePCI-Express 5.0
  • Max Sequential ReadUp to 14500 MBps
  • Max Sequential WriteUp to 9300 MBps

Option 15.36TB E3.S

  • 1.92TB E3.S
  • 1.92TB E3.S FIPS
  • 1.92TB E3.S Opal
  • 1.92TB U.2
  • 1.92TB U.2 FIPS
  • 1.92TB U.2 Opal
  • 15.36TB E3.S
  • 15.36TB E3.S FIPS
  • 15.36TB E3.S Opal
  • 15.36TB U.2
  • 15.36TB U.2 FIPS
  • 15.36TB U.2 Opal
  • 3.84TB E1.S 15mm
  • 3.84TB E1.S 15mm Opal
  • 3.84TB E1.S 9.5mm
  • 3.84TB E1.S 9.5mm Opal
  • 3.84TB E3.S
  • 3.84TB E3.S FIPS
  • 3.84TB E3.S Opal
  • 3.84TB U.2
  • 3.84TB U.2 FIPS
  • 3.84TB U.2 Opal
  • 7.68TB E1.S 15mm
  • 7.68TB E1.S 15mm Opal
  • 7.68TB E1.S 9.5mm
  • 7.68TB E1.S 9.5mm Opal
  • 7.68TB E3.S
  • 7.68TB E3.S FIPS
  • 7.68TB E3.S Opal
  • 7.68TB U.2
  • 7.68TB U.2 FIPS
  • 7.68TB U.2 Opal

Struck-through versions exist but are not stocked here.

  • 14,500 MB/s sequential read speeds up large dataset access
  • 9,300 MB/s sequential write accelerates data ingest workloads
  • 2,750,000 random read IOPS handles latency-sensitive transactions
  • 380,000 random write IOPS sustains mixed I/O performance
  • 36TB capacity consolidates storage in a 7.5mm E3.S form factor

Enterprise E3.S SSD

The Solidigm D7-PS1010 SB5PHA7X153T001 is a 15.36TB enterprise solid-state drive built in the E3.S 7.5mm form factor. It connects through a PCI-Express 5.0 x4 interface and uses 176L TLC 3D NAND. The drive is rated for 1 DWPD endurance with 28 PBW total bytes written and an MTBF of 2,500,000 hours. Active power draw reaches 23W while idle power is 5W.

Target workloads and exclusions

This drive suits data-centre servers that need high-capacity, read-intensive storage in the E3.S 7.5mm slot. It is not for systems that lack an E3.S backplane or PCIe 5.0 support. Buyers who need higher write endurance or a different physical form factor should look elsewhere.

Deciding specification

The E3.S 7.5mm form factor combined with a PCI-Express 5.0 x4 interface determines whether this drive fits the target server. Verify the chassis slot and backplane electrical specification before purchase.

Highlights

  • 14,500 MB/s sequential read speeds up large dataset access
  • 9,300 MB/s sequential write accelerates data ingest workloads
  • 2,750,000 random read IOPS handles latency-sensitive transactions
  • 380,000 random write IOPS sustains mixed I/O performance
  • 36TB capacity consolidates storage in a 7.5mm E3.S form factor

Specifications

BrandSolidigm
ModelD7-PS1010
Part NumberSB5PHA7X153T001
Form FactorE3.S 7.5mm
Capacity15.36TB
Memory Components176L TLC 3D NAND
InterfacePCI-Express 5.0
Max Sequential ReadUp to 14500 MBps
Max Sequential WriteUp to 9300 MBps
4KB Random Read2750000 IOPS (4K Blocks)
4KB Random Write380000 IOPS (4K Blocks)
Endurance1 DWPD / 28 PBW
MTBF2,500,000 hours
Power Consumption (Idle)5W
Power Consumption (Active)23W
Operating Temperature0°C to 77°C
Max Shock Resistance1,000 G (Max) at 0.5 msec
Max Vibration ResistanceOperating: 2.17 GRMS (5 - 700 Hz) Max
Non-Operating: 3.13 GRMS (5 - 800 Hz) Max
Weight120g +/- 10g
Shipping weight0.23 kg
Package size155 × 108 × 19 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How often will the 15.36TB drive need replacement under a 1 DWPD write load?

The 28 PBW endurance rating means the 15.36TB drive can absorb one full drive write per day for five years before replacement is required.

Which limit appears first during sustained heavy writes on the 15.36TB model?

The 1 DWPD endurance ceiling is reached before the 2,500,000-hour MTBF or the 9300 MBps sequential write ceiling under continuous heavy write workloads.

What heat and power should I expect from the E3.S 7.5mm drive running all day at 23W active power?

At 23W active power the drive stays within the 0°C to 77°C operating window; ensure the chassis airflow can remove roughly 23W per drive continuously.
