Rectangular metal ATX power supply unit with matte black finish and rear fan grille

Sparkle Power Inc.

Sparkle Power Inc. SPI700W7BB-B204 700 W power supply

SKU CH-5HQQ-WZ076 MPN SPI700W7BB-B204

A 700 W ATX12V / EPS12V unit with active PFC, 80 PLUS Bronze efficiency and four +12 V rails rated at 16 A each

  • TypeATX12V / EPS12V
  • Maximum Power700 W
  • PFCActive
  • Energy-Efficient80 PLUS BRONZE Certified
  • Over Voltage ProtectionYes
  • Overload ProtectionYes
  • Efficient operation with 80 PLUS Bronze certification
  • Stable delivery across four independent +12 V rails at 16 A each
  • Worldwide input range from 90 to 264 V at 47 to 63 Hz
  • Long-life reliability rated beyond 100,000 hours MTBF
  • Comprehensive safety with over-voltage, overload and short-circuit protection

700 W ATX12V EPS12V unit

The Sparkle Power SPI700W7BB-B204 is a 700 W ATX12V and EPS12V power supply with active PFC and 80 PLUS Bronze certification. It delivers four +12 V rails rated at 16 A each plus 3.3 V at 24 A and 5 V at 30 A for multi-rail stability.

Suits standard ATX builds not high current single

This unit fits builders who need Bronze efficiency and full safety approvals including FCC Class B, TUV, cUL and RoHS. It does not suit systems that demand a single high-current +12 V rail or power levels above 700 W.

Standard ATX dimensions simplify fitting

At 2.80 by 3.90 by 10.20 inches and 5.00 lbs it matches common ATX bays and uses a remote on/off function for flexible wiring. Installers should verify case depth clearance and ensure all four +12 V connectors reach the motherboard and GPU without strain.

Highlights

  • Efficient operation with 80 PLUS Bronze certification
  • Stable delivery across four independent +12 V rails at 16 A each
  • Worldwide input range from 90 to 264 V at 47 to 63 Hz
  • Long-life reliability rated beyond 100,000 hours MTBF
  • Comprehensive safety with over-voltage, overload and short-circuit protection

Specifications

BrandSparkle Power
ModelSPI700W7BB-B204
TypeATX12V / EPS12V
Maximum Power700 W
PFCActive
Energy-Efficient80 PLUS BRONZE Certified
Over Voltage ProtectionYes
Overload ProtectionYes
Input Voltage90 - 264 V
Input Frequency Range47 - 63 Hz
Output+3.3V@24A / 0.5A, +5V@30A / 0.5A, +12V1@16A / 0.5A, +12V2@16A / 0.5A, +12V3@16A / 0.5 A, +12V4@16A / 0.5A, [email protected] / 0.05A, +5VSB@4A / 0.1A
MTBF>100,000 Hours
ApprovalsFCC Class B certified, TUV, CISPR 22 Class B, cUL, EN 61000-3-2, CB, EMC, FCC Part 15, RoHS, UL 60950-1, EN 60950-1, 80 PLUS Bronze
FeaturesShort-circuit protection, remote ON / OFF function
Dimensions2.80" x 3.90" x 10.20"
Weight5.00 lbs.
Shipping weight2.84 kg
Package size285 × 135 × 105 mm

Questions about this item

What motherboard power connectors does the SPI700W7BB-B204 require to be present on the board?

The unit follows the ATX12V / EPS12V specification, so the motherboard must provide a 24-pin main connector and either a 4-pin or 8-pin EPS12V CPU connector.

Will the four +12 V rails each limited to 16 A support older graphics cards that draw all 12 V current from a single rail?

The supply splits the +12 V output across four rails rated at 16 A each; a legacy card that expects a single high-current rail may exceed one rail limit if its draw surpasses 16 A.

How can I confirm the 80 PLUS Bronze efficiency is being met after installation?

Use a power meter at the wall outlet and compare AC input watts to the DC load reported by monitoring software; the ratio should reach the 80 PLUS Bronze level.
