Supermicro
Supermicro AS -1115S-FWTRT-02-G1 1U rack server EPYC 8124P 16C 128GB DDR5 1.92TB SATA 480GB NVMe 2x 800W
1U rack server with 16-core EPYC 8124P, 128GB DDR5-5600, 1.92TB SATA and 480GB NVMe storage, dual 10GbE RJ45, redundant 800W platinum power
- WorkloadEdge Server
- TypeRack
- Rack Height1U
- CPU TypeAMD EPYC 8004 Series
- CPU Speed8124P (2.45 GHz)
- Number of CPU Cores16-Core Processor
- 16-core EPYC 8124P handles edge workloads efficiently
- 128GB DDR5-5600 memory supports responsive multitasking
- 92TB SATA SSD provides high-capacity storage
- 480GB NVMe drive accelerates boot and cache
- Dual 10GbE ports enable fast network throughput
Gold Series Edge Server
The Supermicro AS -1115S-FWTRT-02-G1 is a 1U rack server built for edge workloads. It ships with a single AMD EPYC 8124P 16-core processor running at 2.45 GHz, 128GB of DDR5-5600 memory, and dual 800W platinum power supplies.
Suited for edge deployments needing dual 10GbE
This system fits sites that require onboard dual 10GbE RJ45 connectivity, a 480GB M.2 NVMe boot drive, and a 1.92TB 2.5-inch SATA SSD in a 1U chassis. Buyers who need more than one processor socket, more than 256GB maximum memory, or additional drive bays should look at a different platform.
Single-socket EPYC 8004 platform limits CPU
The motherboard supports a maximum of one processor, so compute capacity is fixed at the installed 16 cores. If the workload demands dual-socket scaling or a higher core count, this server cannot meet that requirement.
Highlights
- 16-core EPYC 8124P handles edge workloads efficiently
- 128GB DDR5-5600 memory supports responsive multitasking
- 92TB SATA SSD provides high-capacity storage
- 480GB NVMe drive accelerates boot and cache
- Dual 10GbE ports enable fast network throughput
Specifications
| Brand | SUPERMICRO |
|---|---|
| Series | Gold Series |
| Model | AS -1115S-FWTRT-02-G1 |
| Workload | Edge Server |
| Type | Rack |
| Rack Height | 1U |
| CPU Type | AMD EPYC 8004 Series |
| CPU Speed | 8124P (2.45 GHz) |
| Number of CPU Cores | 16-Core Processor |
| Cache Memory | 64 MB |
| # of Processors Installed | 1 |
| MAX Processors | 1 |
| Installed Memory Size | 128GB |
| Memory Type | DDR5 5600 |
| Memory Features | Max Memory (2DPC): Up to 256GB 2933MT/s ECC DDR4 RDIMM |
| SSD (Installed) | 1 x 480GB M.2 7450 PRO NVMe PCIe 4.0 Solid State Drive 1 x 1.92TB 2.5" PM893 SATA 6Gb/s Solid State Drive (1 x DWPD) |
| Ethernet Controller | 1 x 2 10GbE RJ45 Ports |
| Power Characteristics | 2 x 800W Platinum Level |
| Shipping weight | 11.34 kg |
| Package size | 686 × 610 × 203 mm |
Questions about this item
Will the dual 10GbE RJ45 ports connect directly to my existing 1GbE switch without extra modules?
Yes, the onboard dual 10GbE RJ45 ports auto-negotiate down to 1GbE so they link to older copper switches using standard Cat5e or Cat6 cables.
Which front-panel LEDs or management interface confirm the EPYC 8124P and both SSDs are healthy after first power-on?
The front status LEDs show power, drive activity and system health, while the BMC web interface reports CPU temperature, DDR5 ECC status and SMART data for the 1.92TB SATA and 480GB NVMe drives.
Which items ship inside the chassis — rails, bezel, cable management arm or just the server with the two 800W power supplies?
The unit ships as a complete 1U server with the EPYC 8124P, 128GB DDR5-5600, 1.92TB SATA SSD, 480GB NVMe SSD and two 800W Platinum supplies installed; rack rails and bezel are optional accessories.
