Green mATX server board with silver LGA 1700 socket, four black DDR5 slots, eight blue SATA ports, dual RJ45 and VGA rear I/O

Supermicro

Supermicro MBD-X13SCL-F-O LGA 1700 mATX server motherboard

SKU CH-M004-Y7XA9 MPN MBD-X13SCL-F-O

mATX server board with LGA 1700 socket, four DDR5 4400 slots for up to 128 GB ECC, eight SATA 6 Gb/s ports with RAID, one PCIe 5.0 x8, one PCIe 5.0 x8 in x16 slot, two PCIe 4.0 x4 slots.

  • CPU Socket TypeLGA 1700
  • CPU TypeIntel Xeon 6300-series/ E-2400/Pretium Processor
  • Number of Processor Support1
  • CPU FeaturesUp to 95W TDP
  • North BridgeIntel C262
  • Memory Slots4 x DDR5 288-pin
  • Supports Intel Xeon 6300-series and E-2400 processors up to 95W TDP
  • Four DDR5 288-pin slots deliver up to 128GB ECC memory at 4400MHz
  • Eight SATA 6.0Gb/s ports with RAID 0/1/5/10 via Intel C262
  • Dual Intel I210 Gigabit LAN provides two 1Gbps network connections
  • PCIe 5.0 x8 plus PCIe 4.0 x4 M.2 slot enable high-speed expansion

LGA 1700 mATX server motherboard

The Supermicro MBD-X13SCL-F-O is a micro-ATX server board built around the Intel C262 chipset and a single LGA 1700 socket. It accepts Intel Xeon 6300-series, E-2400 and Pentium processors up to 95W TDP. Four DDR5 288-pin slots support ECC unbuffered memory at 4400MHz with a maximum capacity of 128GB. Onboard graphics are provided by an Aspeed AST2600 controller and dual gigabit LAN uses Intel I210 chipsets.

Builders needing dense storage or Gen 5 expansion

Eight SATA 6.0Gb/s ports with RAID 0, 1, 5 and 10 suit storage-heavy nodes, while one PCIe 5.0 x8 slot and a second PCIe 5.0 x8 wired into a x16 connector accommodate modern add-in cards. Two additional PCIe 4.0 x4 slots in x8 connectors handle secondary peripherals. A single M.2 M-key slot supports 2280 or 22110 form factors over PCIe 4.0 x4. Rear I/O includes dual LAN, COM, VGA, two USB 2.0 and three USB 3.2 Gen 1 ports.

Systems limited to 95W CPU power

The socket is rated for processors up to 95W TDP, so higher-wattage Xeon models cannot be used. This thermal ceiling defines which CPUs the board can support and must be checked before selecting a processor.

Highlights

  • Supports Intel Xeon 6300-series and E-2400 processors up to 95W TDP
  • Four DDR5 288-pin slots deliver up to 128GB ECC memory at 4400MHz
  • Eight SATA 6.0Gb/s ports with RAID 0/1/5/10 via Intel C262
  • Dual Intel I210 Gigabit LAN provides two 1Gbps network connections
  • PCIe 5.0 x8 plus PCIe 4.0 x4 M.2 slot enable high-speed expansion

Specifications

BrandSUPERMICRO
ModelMBD-X13SCL-F-O
CPU Socket TypeLGA 1700
CPU TypeIntel Xeon 6300-series/ E-2400/Pretium Processor
Number of Processor Support1
CPU FeaturesUp to 95W TDP
North BridgeIntel C262
Memory Slots4 x DDR5 288-pin
Memory StandardDDR5 4400
Maximum Memory Supported128GB
ECC SupportedYes
PCI Express x81 x PCIe 5.0 x8
1 x PCIe 5.0 x8 (in x16 slot)
PCI Express x42 x PCIe 4.0 x4 (in x8 slot)
SATA8 x SATA 6.0Gb/s
SATA RAID0/1/5/10
M.2M.2 Interface: 1 PCIe 4.0 x4
Form Factor: 2280/22110
Key: M-Key
Onboard Video ChipsetAspeed AST2600
LAN ChipsetIntel I210
LAN Speed10/100/1000Mbps
Max LAN Speed2 x 1Gbps
Back I/O Ports1 x COM (Serial Port) / 1 x D-Sub / 2 x LAN (RJ45) / 2 x USB 2.0/1.1 / 3 x USB 3.2 Gen 1
BIOS FeatureAMI 32MB AMI UEFI
ACPI 6.4
SMBIOS 3.5
UEFI 2.8
Plug and Play (PnP)
PCI FW 3.3
Form FactorMicro ATX
Dimensions (W x L)9.6" x 9.6"
Shipping weight1.00 kg
Package size286 × 274 × 55 mm

Questions about this item

How much heat should I expect from the 95W TDP limit when the board runs continuously?

The LGA 1700 socket is rated for CPUs up to 95W TDP, so sustained thermal output will stay within that envelope; pair it with a server-grade cooler sized for 95W to maintain stable temperatures.

Which DDR5 modules do I need to populate the four 288-pin slots?

Install unbuffered DDR5-4400 ECC DIMMs; the board supports up to 128GB total across the four slots.

Can I keep using my existing SATA drives and PCIe 4.0 add-in cards with this motherboard?

Yes — eight SATA 6.0Gb/s ports with RAID 0/1/5/10 and two PCIe 4.0 x4 slots (in x8 physical) accept current SATA drives and PCIe 4.0 cards directly.
